Transfer Corona section

10.2 Drive

10.2.1

1st Image Transfer section

[9]
[8]
[1] Transfer Belt
[2] Main Motor (M1)
[3] Sliding Plate
[4] Cam
[5] 1st Image Transfer Roller/Y
QC 2235plus Theory of Operation Ver.1.0 Feb. 2004
[1]
[10]
[7]
[6] 1st Image Transfer Roller/M
[7] 1st Image Transfer Retraction Position Sensor (PC12)
[8] 1st Image Transfer Pressure/Retraction Motor (M11)
[9] 1st Image Transfer Roller/C
[10] 1st Image Transfer Roller/Bk
2-34
[2]
4036ma2020c1
[3]
[4]
[5]
[6]
4036ma2158c0
