Product specification
1.3.3

Sort staple/Group staple

Paper Type Paper Size
B5R/B5 to A3
7-1/4 × 10-1/2R/
Plain paper
7-1/4 × 10-1/2
to 11 × 17
*: 20 sheets if originals of high ID (Color Wise 3) is used.
*: 15 sheets when using Color Copy 90 paper.
*: 20 sheets when using Hammermill Laser Print90 paper.
1.4

Stapling

Staple Filling Mode Dedicated Staple Cartridge Mode (3000 staples)
Staple Detection Available (Nearly Empty: 40 remaining staples)
Diagonal back side (45 °C) 1 point
Stapling Position
Rear Parallel 1 point
B5R/B5 to A3
Stapled Paper Size
8-1/2 × 11R / 8-1/2 × 11 to 11 × 17
Manual Staple None
1.5

Sort and staple capacity

1.5.1 Stacking with no stapling, with the same size paper (80g/m
• Determined by the item whose value is reached first among number of stacked paper,
stacked height or mass of stack.
• Determined by the stacked height when stacking with stapling and no stapling mixed.
A. Number of stacked paper
FD
A4R, 8-1/2 × 11R or smaller
B4, 8-1/2 × 14 or larger
B. Stacked height
FD
A4R, 8-1/2 × 11R or smaller
B4, 8-1/2 × 14 or larger
C. Mass of stack
FD
A4R, 8-1/2 × 11R or smaller
B4, 8-1/2 × 14 or larger
QC 2235plus Theory of Operation Ver.1.0 Mar. 2004
Weight Tray Capacity
2
60 to 90 g/m
1,000 sheets
16 to 24 lb
(A4R, 8-1/2 ×
11R or
Cover Mode
smaller);
91 to 209
500 sheets
2
g/m
(B4, 8-1/2 × 14
24-1/4 to
or larger)
55-1/2 lb
No. of Sheets
1000 sheets
500 sheets
Height
150 mm
75 mm
Mass
correspond to 1000 sheets
correspond to 500 sheets
1-2
No. of Sheets to
Exit Tray
be Stapled
30 sheets
Elevator Tray
(60 to 80 g/m
16 to 21-1/4 lb)
2
)
2
,
