Serial Commands
Serial Configuration Commands
The following serial commands can be entered through ESP's Terminal to control QX-830
functions. Detailed descriptions of command parameters are available in Chapter 5,
Scanner Parameters.
Communication
RS-232 A
RS-232 B
RS-422
Ethernet
Ethernet TCP Ports
EtherNet/IP
RS-232 A Data Type
RS-232 B Data Type
RS-422 Data Type
Ethernet TCP Port 1 Data Type
Ethernet TCP Port 2 Data Type
EtherNet/IP Data Type
Preamble
Postamble
Response Timeout
LRC Status
ACK/NAK Options
Polling Mode Options
Autoconfiguration Daisy Chain
Protocol Selection
External Data Routing
Array Communication Modes
RS-232 A
Baud Rate, RS-232 A
Serial Cmd: <K100,baud
Default: 8 = 115.2K
Options: 0 = 600
3 = 4800
6 = 38.4K
9 = 230K
A-16
<K100,baud rate,parity,stop bits,data bits>
<K101,status,baud rate,parity,stop bits,data bits>
<K102,status,baud rate,parity,stop bits,data bits>
<K126,status,IP address,subnet,gateway,IP address mode>
<K127,TCP Port 1,TCP Port 2>
<K129,status>
<K130,symbol data output,extra symbol information,diagnostic
output,external source processing mode>
<K131,symbol data output,extra symbol information,diagnostic
output,external source processing mode>
<K132,symbol data output,extra symbol information,diagnostic
output,external source processing mode>
<K133,symbol data output,extra symbol information,diagnostic
output,external source processing mode>
<K134,symbol data output,extra symbol information,diagnostic
output,external source processing mode>
<K136,symbol data output,extra symbol information,diagnostic
output,external source processing mode>
<K141,status,preamble>
<K142,status,postamble>
<K143,response timeout>
<K145,status>
<K147,RES,REQ,STX,ETX,ACK,NAK>
<K148,RES,REQ,STX,ETX,ACK,NAK>
<K150DAISY>
<K160,protocol,address,protocol port>
<K161,mode,destination port,ambles to source,echo to
source,output at end of read cycle,output at ETX,output at timeout>
<K162,mode,source,daisy chain i.d. status,daisy chain i.d.>
rate,parity,stop bits,data bits>
1 = 1200
4 = 9600
7 = 57.6K
