Canon iPF6100 Service Manual page 52

Chapter 1
4. Main Menu Settings
Main menu items are described in the following tables.
Setting Item
[Paper Cut]
[Rep. Ink Tank]
[Head Cleaning]
[Paper Settings]
[Paper Details]
[Adjust Printer]
[Interface Setup]
[Maintenance]
[System Setup]
[Test Print]
[Information]
[Paper Settings]
Setting Item
[Roll Media Type]
[Chk Remain.Roll]
[Roll Length Set]
[Cut Sheet Type]
1-40
Displayed if a roll is loaded.
Choose Yes to cut the roll at the current position. The paper will be fed, if necessary,
so that the sheet is at least 10 cm (39.4 in.)long after the cut. The paper will not be
cut if there is not enough paper left to feed the paper this much.
When exchanging the ink tank, choose Yes and follow the instructions on the
screen.
Specify Printhead cleaning options.
Choose Head Cleaning A if printing is faint, oddly colored, or contains foreign
substances.
Choose Head Cleaning B if no ink is printed at all, or if printing is not improved by
Head Cleaning A .
Specify the type and size of paper.
Specify detailed paper-related settings, including the ink drying time and borderless
printing options.
Adjust the Printhead alignment or amount of feed by printing a test pattern.
Configure the network settings.
Replace the Printhead , prepare to transfer the printer, and clean the Pick Up Roller .
Specify the printer system settings, including the date format and display language.
Choose Status Print to print information about the printer.
Choose Media Details to print the paper settings as specified in Med.Detail Set. .
Choose Print Job Log to print a record of print jobs, including the paper type and
size, amount of ink used, and so on.
Choose Menu Map to print a list of the main menu options.
Choose Nozzle Check to print a test pattern for checking the nozzles.
If you have selected a leading edge margin of 20 mm in Nr End Sht Mrgn in the
printer menu, the test print sheet may not be printed completely.
Displays the information about the printer and history of print jobs.
Choose the type of roll.
Choose On to print a barcode at the end of a roll before you remove it. The printed
barcode can be used in managing the amount of roll paper left. Choose Off if you
prefer not to print the barcode.
Displayed if Chk Remain.Roll is On .
If a barcode is not printed on rolls, specify the roll length. The roll length is
displayed in meters (1.0 - 91.0 m) or feet (1 - 300 ft.), depending on the setting in
Length Unit .
Choose the type of cut sheet.
T-1-14
Description, Instructions
T-1-15
Description, Instructions
