Fenix SM2000 Operation Manual page 49

FENIX IMVICO
FS p n m
[Name] Print NV bit image
[Format] ASCII
Hex
Decimal
1 ≤ n ≤ 2
[Range]
0 ≤ m ≤ 3, 48 ≤ m ≤ 51
[Description] Prints a NV bit image n using the mode specified by m.
m
0, 48
1, 49 Double-width
2,50 Double-height
3,51 Quadruple
[dpi: dots per 25.4 mm]
•
n is the number of the NV bit image (defined using the FS q command).
•
m specifies the bit image mode.
[Notes]
•
NV bit image means a bit image which is defined in a non-volatile memory by FS q and
printed by FS p.
•
This command is not effective when the specified NV bit image has not been defined.
•
This command is effective only when there is no data in the print buffer.
•
This command is not affected by print modes (emphasized, double-strike, underline,
character size, white/black reverse printing, or 90° rotated characters, etc.).
•
If the printing area width set by GS L for the NV bit image is less than one vertical
line, the following processing is performed only on the line in question. However, in NV bit
image mode, one vertical line means 1 dot in normal mode (m =0, 48) and in double-height
mode (m =2, 50), and it means 2 dots in double-width mode (m =1, 49) and in quadruple
mode (m=3, 51).
The printing area width is extended to the right in NV bit image mode up to one line
vertically. In this case, printing does not exceed the printable area.
If the printing area width cannot be extended by one line vertically, the left margin is
reduced to accommodate one line vertically.
•
If the downloaded bit-image to be printed exceeds one line, the excess data is not printed.
•
This command feeds dots (for the height n of the NV bit-image) in normal and double-width
modes, and (for the height n ×2 of the NV bit-image) in double-height and quadruple modes,
regardless of the line spacing specified by ESC 2 or ESC 3.
•
After printing the bit image, this command sets the print position to the beginning of the line
and processes the data that follows as normal data.
•
GS / m command operates like FS q n m (n=1).
[Reference] FS q, GS v 0
FS p
1C 70
28 112
Mode Vertical Dot Density
Normal 203.2 dpi
203.2 dpi
101.6 dpi
101.6 dpi
n m
n m
n m
Horizontal Dot Density
SM2000 OPERATION MANUAL
203.2 dpi
101.6 dpi
203.2 dpi
101.6 dpi
49/65
