LF
[Name] Print and line feed
[Format] ASCII
Hex
Decimal
[Description] Prints the data in the print buffer and feeds one line based on the current line spacing.
[Notes] This command sets the print position to the beginning of the line.
[Reference] ESC 2, ESC 3.
CR
[Name] Print and carriage return
[Format] ASCII
Hex
Decimal
[Description] When automatic line feed is enabled, this command functions the same as LF; when
automatic line feed is disabled, this command is ignored.
[Notes]
•
Sets the print starting position to the beginning of the line.
•
The automatic line feed is ignored with a serial interface model.
•
This command is set according to the DIP switch 1-1 setting with a parallel interface model.
[Reference] LF
DLE EOT n
[Name] Real-time status transmission
[Format] ASCII
Hex
Decimal
<01>H ≤ n ≤ <04>H
[Range]
[Description] Transmits the selected printer status specified by n in real-time, according to the
following parameters:
[Notes]
•
The status is transmitted whenever the data sequence of <10>H<04>H<n>(1< n < 4) is
received.
•
The printer transmits the current status. Each status is represented by one-byte data.
•
The printer transmits the status without confirming whether the host computer can receive
data (serial interface).
•
This command is executed even when the printer is offline or there is an error status with a
serial interface model.
n = <01>H: Printer status
Bit OFF/ON
0 OFF Not used. Fixed to Off.
1 ON Not used. Fixed to On.
OFF Drawer open/close signal is LOW (connector pin 3).
2
ON Drawer open/close signal is HIGH (connector pin 3).
OFF Online.
3
ON Offline.
4 ON Not used. Fixed to On.
5,6 - Undefined.
7 OFF Not used. Fixed to Off.
LF
0A
10
CR
0D
13
DLE EOT
10 04
16 4
n = <01>H: Transmit printer status
n = <02>H: Transmit offline status
n = <03>H: Transmit error status
n = <04>H: Transmit paper roll sensor status
n
n
n
Function
