GS ! n
[Name] Select character size
[Format] ASCII
Hex
Decimal
0≤ n ≤ 255
[Range]
(1 ≤ vertical number of times ≤ 8, 1 ≤ horizontal number of times ≤ 8)
[Description] Selects the character height using bits 0 to 2 and selects the character width using bits 4
to 7, as follows:
Bit
0
1
2
3
4
5
6
7
Table 1
Character Height Selection
Hex Decimal
00 0
01 1
02 2
03 3
04 4
05 5
06 6
07 7
[Notes]
•
This command is all characters effective except for HRI characters.
•
If n is outside of the defined range, this command is ignored.
•
The vertical direction is the paper feed direction, and the horizontal direction is perpendicular
to the paper feed direction. However, when character orientation changes in 90° clockwise-
rotation mode, the relationship between vertical and horizontal directions is reversed.
•
When characters are enlarged with different sizes on one line, all the characters on the line
are aligned at the baseline.
•
The ESC ! command can also turn double-width and double-height modes on or off.
However, the setting of the last received command is effective.
[Default] n = 0
[Reference] ESC !
GS ( A pL pH n m
[Name] Execute test print
[Format] ASCII
Hex
Decimal
[Range] (pL + (pH x 256)) = 2
0 ≤ n ≤ 2, 48 ≤ n ≤ 50
1 ≤ m ≤ 3, 49≤ m ≤ 51
[Description]
•
Executes a test print with a specified test pattern on a specified paper.
•
p and p specifies the number of the parameter such as n, m to (p
L H
n specifies the paper to be tested.
GS !
1D 21
29 33
OFF / ON Hex
Character height selection. See Table 1.
Character width selection. See Table 2.
Height
1 (normal)
2 (double-height)
3
4
5
6
7
8
GS (
1D 28
29 40
(pL = 2, pH = 0)
n
n
n
Decimal Function
Character Width Selection
Hex Decimal
00 0
10 16
20 32
30 48
40 64
50 80
60 96
70 112
A pL pH
41 pL pH
65 pL pH
SM2000 OPERATION MANUAL
Table 2
Width
1 (normal)
2 (double-width)
3
4
5
6
7
8
n m
n m
n m
+ (p x 256)) bytes.
L H
