, select the number of data bytes (xL+xH x 256) in the horizontal direction for the bit
L
H
image.
y
, y
, select the number of data bytes (yL+yH x 256) in the vertical direction for the bit
L
H
image.
[Notes]
This command is effective only when there is no data in the print buffer.
This command has no effect in all print modes (character size, emphasized, double-strike,
upside-down, underline, white/black reverse printing, etc.) for raster bit image.
Data outside the printing area is read in and discarded on a dot-by-dot basis.
The position in which the later characters must be printed for the plot of the bit image this
specified by GS L (Fixed the left margin).
If the printing area width set by GS L is less than the minimum width, the printing
area is extended to the minimum width only on the line in question. The minimum width
means 1 dot in normal (m=0, 48) and double-height (m=2, 50), 2 dots in double-width (m=1,
49) and quadruple (m=3, 51) modes.
The ESC a (Select justification) setting is also effective on raster bit images.
d indicates the bit-image data. Setting it to 1 prints a dot and setting it to 0 does not print a
dot.
When x
[Example]
GS w n
[Name]
Set bar code width
[Format]
ASCII
Hex
Decimal
2 ≤ n ≤ 6
[Range]
[Description]
Set the horizontal size of the bar code.
n specifies the bar code width as follows:
n
2
3
4
5
6
Multi-level bar codes are as follows:
JAN 13(EAN13), CODE 128.
Binary-level bar codes are as follows:
ITF, CODE39
[Default]
n = 3
[Reference]
GS k
+x
256=64
L
H⋅
GS
w
1D
77
29
119
Module Width (mm) for
Multi-level Bar Code
0.282
0.423
0.564
0.706
0.847
n
n
n
Binary-level Bar Code
Thin element width
(mm)
0.282
0.426
0.564
0.706
0.847
SM2000 OPERATION MANUAL
Thick element width
(mm)
0.706
1.129
1.411
1.834
2.258
48/65
