3.3.4.2- DIP-switch configuration for the parallel interface.

switch
1 Auto line advance
2
3-8
switch
1 Protocol (BUSY condition)
2
3 It selects the printing density /
4 low power consumption mode
5
6
7
8
Level Function
- Low power consumption mode
1 Printing density normal
2 Printing density half
3 Printing density high
Table 3.7- DIP Switch 2-3 and 2-4 (PARALLEL).
NOTES:
• The changes in the DIP-switch settings are read initially, when the SM2000 is powered on. If
the DIP-switch configuration is changed after powering the unit on, the change does not
have any effect.
• In low power consumption mode, the printing speed is fixed to a maximum of 100 mm/s.
DIP-switch 1
Function
Always enabled
---
---
Table 3.5- DIP switch 1(PARALLEL).
DIP-switch 2
Function
---
---
---
---
---
Table 3.6- DIP switch 2 (PARALLEL)
SM2000 OPERATION MANUAL
ON OFF
Always disabled
---
---
ON
• Receiving buffer full
---
Refer to table 3.3.7
---
---
---
---
SW 2-3 SW 2-4
ON ON
OFF OFF
ON OFF
OFF ON
---
---
OFF
• Off line
• Receiving buffer full
---
---
---
---
---
