FENIX IMVICO
ESC E n
[Name]
Turn emphasized mode on/off
[Format]
ASCII
Hex
Decimal
0 ≤ n ≤ 255
[Range]
[Description]
Turns emphasized mode on or off
When the LSB of n is 0, emphasized mode is turned off.
When the LSB of n is 1, emphasized mode is turned on.
[Notes]
Only the least significant bit of n is enabled.
This command and ESC ! turn on and off emphasized mode in the same way. Be careful
when this command is used with ESC !.
[Default]
n = 0
[Reference]
ESC !, ESC G
ESC G n
[Name]
Turn on/off double-strike mode
[Format]
ASCII
Hex
Decimal
0 ≤ n ≤ 255
[Range]
[Description]
Turns double-strike mode on or off.
When the LSB of n is 0, double-strike mode is turned off.
When the LSB of n is 1, double-strike mode is turned on.
[Notes]
Only the lowest bit of n is enabled.
Printer output is the same in double-strike mode and in emphasized mode.
[Default]
n = 0
[Reference]
ESC E
ESC J n
[Name]
Print and feed paper
[Format]
ASCII
Hex
Decimal
0 ≤ n ≤ 255
[Range]
[Description]
Prints the data in the print buffer and feeds the paper [n x horizontal or vertical motion
units].
[Notes]
After printing is completed, this command sets the print starting position to the beginning of
the line.
The paper feed amount set by this command does not affect the values set by ESC 2 or
ESC 3.
In standard mode, the printer uses the vertical motion unit (y).
The maximum line spacing is 1016mm. When the setting value exceeds the maximum,
it is converted to the maximum automatically.
ESC
E
n
n
1B
45
27
69
n
ESC
G
n
1B
47
n
27
71
n
ESC
J
n
1B
4A
n
27
74
n
SM2000 OPERATION MANUAL
38/65
