Appendix A / Adjustment of short-cycle drawn arc welding guns
Item No. Qty.
42 1
43 1
44 1
45 3
46 3
47 1
48 1
49 1
50 3
51 1
52 1
53 1
54 2
55 1
56 1
*** 1
Designation
Lifting magnet with armature
Holding device for magnet
Lift adjuster
Spring washer M3 DIN127A
Cheese-head screw M3x20 DIN912
Acorn nut M4 DIN6797A
Tooth lock washer M4 DIN6797A
Fillister head screw M4x8 DIN ISO 7380
Spring thrust piece M4x10
Gun label for PH-3N
Straight pin 6m6x36 DIN6325
Spring guide for piston
Bushing with recirculating ball bearing
Pressure spring
Working piston
Screw kit comprising items:
2/8/9/13/15/17/26/41/45/46/47/48/49/50/52
Order No.
E03654
F04036
F04035
***
***
***
***
***
***
M03596
***
F03879
F03888
F03880
F03887
F04662/FA
Appendix A /11
