BMK-12 W
6.1.2

Welding parameters for welding operation

IMPORTANT
The set welding parameters influence the reproducibility and quality of the welding
results to a large extent. The parameters depend on the size of the studs and the
material properties. The values indicated in the tables are standard values which are
exclusively valid for studs supplied by SOYER. They may vary depending on the type
of workpiece, the workpiece thickness, the surface condition of the workpiece and on
environmental conditions (e.g. low outdoor temperatures). The settings of the welding
gun or welding head influence the welding parameters as well.
Random samples should be taken during any production process to ensure constantly
good welding results (see DIN EN ISO 14 555, "Arc welding of metallic materials")
The welding parameters were determined with the BMK-12 W stud welder and the
PH-3N stud welding gun having a lift setting of about 2.5 mm.
A steel plate with a thickness of 5 mm was used as base material for welding SOYER
welding studs as per DIN EN ISO 13 918.
M3
M4
M5
M6
M8
M10
When using stud diameters exceeding 6 mm, we recommend the application of
shielding gas or ceramic ferrules in order to prevent pore formation and to optimise
bulging.
6.1.3

Minimum sheet thickness when welding with drawn arc operation

Observance of the minimum sheet thickness prevents the plate from being burnt
through during the welding process.
Method
Drawn arc stud welding
with ceramic ferrule or
shielding gas
Short-cycle drawn arc
stud welding
Capacitor discharge
drawn arc stud welding
CF = ceramic ferrule, SG = shielding gas, NP = no weld pool protection
ms
5
RD 6 10 30
PD 6 15 50
RD 8 30 80
PD 8 80 100
RD 10 300 170
PD 10 200
RD 12 220
Weld time
> 100 ms 3 up to 25
mm
> 100 ms 3 up to 16
mm
100 ms 3 up to 12
mm
< 10 ms 3 up to 10
mm
ms
40
40 40
40 40
40 40
40 40
40 40
40
Stud dia. Welding
current
in ampere
300 up to 3000
300 up to 3000
up to 1500
up to 3000
ms
0
0 300
0 300
300 300
300 300
400 400
400
400
Weld pool Minimum
protection sheet
thickness
CF ¼d, but
1 mm min.
SG d, but
1mm min.
NP, SG, CF d, but
0.6 mm min.
NP, SG 1/10d, but
0.5 mm min.
51
