BMK-12 W
5.2.2

Connection of stud welding gun

• Connect welding cable of welding gun to the relevant socket (item 10, chapter 5.1)
and lock it by turning to the right until stop.
• Insert control cable into control cable connection (item 9, chapter 5.1) and tighten
with sleeve nut.
• Please refer to the information given in the operating instructions for the welding
guns.
5.2.3

Gas supply

When welding with shielding gas, provide the following connections:
• Insert gas supply hose's coupler plug of the welding gun into the gas supply socket
(item 11, chapter 5.1) of the stud welder.
• Connect the gas hose of the pressure reducing valve (pressure reducing valve not
included in delivery) to the shielding gas connector (item 19, chapter 5.1) at the rear
side of the stud welder.
5.2.4

Power supply

• Compare the power data (supply voltage / current consumption) on the type plate
(item 18, chapter 5.1) with the data (supply voltage / fuse protection) of your power
supply network.
Connect mains cable (item 13, chapter 5.1) to power supply using the CEE plug
(standard 3 x 400V~, 32A-CEE plug).
Only connect stud welder to authorized CEE sockets.
Standard connection = 3 x 400 V + earth conductor, 32A-CEE. If need be, have an
expert in electrics check if the socket is earthed.
Always comply with the correct line voltage as indicated on the type plate.
Never connect the stud welder to a power supply with the wrong line voltage.
DANGER
39
