  • Page 1 Powerware Series ® ® Eaton BladeUPS Bar Installation Guide...

  • Page 2: Special Symbols

    Pozidriv is a registered trademark of Phillips Screw Company. All other trademarks are properties of their respective companies. ECopyright 2008–2010 Eaton Corporation, Raleigh, NC, USA. All rights reserved. No part of this document may be reproduced in any way without the express written approval of Eaton Corporation.

  • Page 3: Table Of Contents

    ............. . . BladeUPS Bar Installation (Bottom Entry Wireway) .
  • Page 4 TABLE OF CONTENTS 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...

  • Page 5: Introduction

    BladeUPS Bar 4-High: Connects up to four of the BladeUPS modules. BladeUPS Bar 6-High: Connects up to six of the BladeUPS modules. Figure 1 shows the installed BladeUPS Bar in a bottom entry and top entry wireway configuration. The wireway fits into the bottom or top 6U of standard rack space.

  • Page 6: Safety Warnings

    BEWAAR DEZE INSTRUCTIES Deze handleiding bevat belangrijke instructies die u dient te volgen tijdens de installatie en het gebruik van BladeUPS Bar. Lees alle instructies voordat u de apparatuur in bedrijf neemt en bewaar deze handleiding als naslagwerk. TÄRKEITÄ TURVAOHJEITA - SUOMI SÄILYTÄ...

  • Page 7: Wichtige Sicherheitsanweisungen

    VIKTIGE SIKKERHETSINSTRUKSJONER GJEM DISSE INSTRUKSJONENE Denne håndboken inneholder viktige instruksjoner som du bør overholde ved montering og bruk av BladeUPS Bar. Les alle instruksjoner før utstyret tas i bruk, og gjem håndboken til fremtidig referanse. INSTRUÇÕES DE SEGURANÇA IMPORTANTES GUARDE ESTAS INSTRUÇÕES Este manual contém instruções importantes que devem ser seguidas durante a instalação e...

  • Page 8: Instrucciones De Seguridad Importantes

    GUARDE ESTAS INSTRUCCIONES Este manual contiene instrucciones importantes que debe seguir durante la instalación y el funcionamiento del BladeUPS Bar. Por favor, lea todas las instrucciones antes de poner en funcionamiento el equipo y guarde este manual para referencia en el futuro.

  • Page 9: Installation

    15 days of receipt of the equipment; 2) Send a copy of the damage claim within 15 days to your service representative. Setup The BladeUPS Bar comes with all hardware required for installation in a standard EIA or JIS rack with square and round mounting holes. Tools Required...

  • Page 10: Checking The Package Contents

    Ferrite assembly with 38 cm (15”) tie wrap This user's guide Packaged hardware items: - BladeUPS Bar 4-High. (12) M6 12 hex bolts, plus (1) extra - BladeUPS Bar 6-High. (14) M6 12 hex bolts, plus (1) extra - (4) M5 16 hex bolts...

  • Page 11: Bladeups Bar Installation (Bottom Entry Wireway)

    INSTALLATION BladeUPS Bar Installation (Bottom Entry Wireway) To install the BladeUPS Bar in a bottom entry rack: Remove the access cover and terminal block housing from the wireway housing (see Figure 2). Retain the wireway terminal block housing, wireway access cover, and screws. Leave the two side brackets installed on the wireway housing (see side bracket locations in Figure 3).
  • Page 12 Cover Plate Screws (3 places 12 Pan-Head each side) Screws and M6 Split Lock Washers Adjustable Side (3 places each side) Brackets (1 each side) Front of Rack Figure 3. Wireway Installation 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...
  • Page 13 NOTE Verify that the bar is secure as shown in Figure 4. The sheetmetal at the top and bottom of the of the terminal block assembly should fit between the wireway tabs. 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...
  • Page 14 Rear of Rack 12 Hex Bolts (3 places) Terminal Block Assembly Bracket Front of Rack Figure 5. Terminal Block Assembly Installation 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...
  • Page 15 Verify that the terminal block assembly bracket stud aligns completely with the rack hole between the lower and middle bolts (position 5). See Figure 6. Torque the bolts to 5.1 ± 0.8 Nm (45 ± 7 lb in). 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...
  • Page 16 INSTALLATION 15. BladeUPS Bar 4-High. Install two M6 12 hex bolts in each of the bar's two mounting brackets, securing the length of the bar to the rack. See Figure 6. Torque the bolts to 5.1 ± 0.8 Nm (45 ± 7 lb in).
  • Page 17 OUTPUT INPUT OUTPUT Wireway INPUT OUTPUT Terminal Block INPUT 12 Hex Bolts Housing NEUTRAL (2 places) Rear of Rack 8 Pan-Head Screws (6 places) Figure 7. Wireway Terminal Block Housing Installation 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...
  • Page 18 Rear of Rack Figure 8. Wireway Access Cover Installation 21. Verify that the six information labels are attached to the wireway as shown in Figure 9. Labels Figure 9. Wireway Labels 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...
  • Page 19 (45 ± 7 lb in). Bent Edge of Panel 16 Hex Bolts and M5 Cage Nuts (4 places) Front Cover Mounting Panel Front of Rack Figure 10. Front Cover Mounting Panel Installation 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...
  • Page 20 INSTALLATION 23. Snap the two front covers into place, as shown in Figure 11. Front Covers (2 pieces) Front of Rack Figure 11. Front Cover Installation 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...

  • Page 21: Bladeups Bar Installation (Top Entry Wireway)

    INSTALLATION BladeUPS Bar Installation (Top Entry Wireway) To install the BladeUPS Bar in a top entry rack: Remove the access cover and terminal block housing from the wireway housing (see Figure 12). Retain the wireway terminal block housing, wireway access cover, bolts, and screws. Leave the two side brackets installed on the wireway housing (see side bracket locations in Figure 13).
  • Page 22 See Figure 14. 10. Note the orientation of the terminal block assembly bracket installed on the bar for later re-installation (see Figure 15). Remove and retain the terminal block assembly bracket and hardware. 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...
  • Page 23 NOTE Verify that the bar is secure as shown in Figure 14. The sheetmetal at the top and bottom of the of the terminal block assembly should fit between the wireway tabs. 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...
  • Page 24 11 and 17. Verify that the terminal block assembly bracket stud aligns completely with the rack hole between the lower and middle bolts (position 14). See Figure 16. Torque the bolts to 5.1 ± 0.8 Nm (45 ± 7 lb in). 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...
  • Page 25 INSTALLATION 15. BladeUPS Bar 4-High. Install two M6 12 hex bolts in each of the bar's two mounting brackets, securing the length of the bar to the rack. See Figure 16. Torque the bolts to 5.1 ± 0.8 Nm (45 ± 7 lb in).
  • Page 26 1.7 ± 0.2 Nm (15 ± 2 lb in). Front of Rack 12 Hex Bolts (2 places) Wireway Terminal Block Housing Rear of Rack 8 Pan-Head Screws (6 places) Figure 17. Wireway Terminal Block Housing Installation 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...
  • Page 27 Rear of Rack Figure 18. Wireway Access Cover Installation 21. Verify that the six information labels are attached to the wireway as shown in Figure 19. Labels Figure 19. Wireway Labels 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...
  • Page 28 Torque the bolts to 5.1 ± 0.8 Nm (45 ± 7 lb in). Bent Edge of Panel 16 Hex Bolts and M5 Cage Nuts (4 places) Front Cover Mounting Panel Front of Rack Figure 20. Front Cover Mounting Panel Installation 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...
  • Page 29 INSTALLATION 23. Snap the two front covers into place, as shown in Figure 11. Front Covers (2 pieces) Front of Rack Figure 21. Front Cover Installation 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...
  • Page 30 INSTALLATION 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...

  • Page 31: Specifications

    1829 mm (6.0” x 5.7” x 72.0”) Depth of Wireway 901 mm (35.5”), excluding front covers Weight BladeUPS Bar: 18.1 kg (40 lb) BladeUPS Bar: 24.5 kg (54 lb) Wireway enclosure: 20.4 kg (45 lb) Wireway enclosure: 20.4 kg (45 lb) Total weight: 38.5 kg (85 lb)
  • Page 32 SPECIFICATIONS 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...

  • Page 33: Service And Support

    Chapter 4 Service and Support If you have any questions or problems with the BladeUPS Bar, call your Local Distributor or the Help Desk at one of the following telephone numbers and ask for a UPS technical representative. Installation support (toll free)
  • Page 34 A replacement or repair unit will be shipped, freight prepaid for all warrantied units. Help NOTE For critical applications, immediate replacement may be available. Call the Desk for the dealer or distributor nearest you. 164201723 Rev 2 www.eaton.com/powerquality Eaton BladeUPS Bar Installation Guide...

  • Page 35: Warranty

    If the Warranted Item is to be replaced by Eaton, but the End-User is unwilling or unable to supply a credit card number or purchase order for the value of the replacement product, Eaton will use commercially reasonable business efforts to ship (via standard ground shipment and at no cost to the End-User) the replacement Warranted Item to the End-User within one (1) business day after Eaton receives the defective product from the End-User.
  • Page 36 The remedies of the End-User set forth herein are exclusive and are the sole remedies for any failure of Eaton to comply with its obligations hereunder. In no event shall Eaton be liable for any indirect, incidental, special, or consequential damages of any kind or type whatsoever, resulting from, or in connection with, any claim or cause of action, whether brought in contract or in tort (including negligence or strict liability).
  • Page 37 Product, in accordance with the contract terms under which the Product is sold, Eaton shall have no obligation under this Warranty. Also during such time, the period of this Warranty shall continue to run and the expiration of this Warranty shall not be extended upon payment of any overdue or unpaid amounts.
