1. P. E. SHUNT. The shunt has to
be removed when connecting a
Photo Electric Beam.
NOTE: P.E. SHUNT must not be
removed otherwise the opener will
not function correctly. Remove only
when a P.E beam is to be
connected.
2. Terminal is used to connect 24vac
to the control board
3. 10 amps fuse is to protect
the electronic circuit board
4. this connector is used to connect
battery charger sby3 to the opener
5. dc 24v motor connects to this
connector.
6. OPERATE (YELLOW) button is
used during installation to test the
open, stop and close cycles for the
opener. The opener has to be
initialised by the Reset button
before the oprate button becomes
operable.
+
7. PLUS ( ) (GREEN) button is
used During installation to help set
the open limit position. Pressing and
holding this button will move the
door in the open
Movement stops when the button is
released.
8. PROG INPUT is used for the
connection of the ATA Handheld
Programmer for the purpose of
editing control and
functions.
9. LED light module connector is
used to connect 24v led light
module

OPERATING CONTROLS

10. FORCE MARGIN SET Button
The obstruction force pressure is
set automatically by the opener
during installation. The pressure can
be adjusted manually using the
Force Margin Set button . Holding
the Force Margin Set button and
pressing the Plus (+) or Minus
(-) button will increase or decrease
the amount of force. The Force
Margin Set is only ever used if other
environmental factors (wind, etc.)
effect the
door/opener.
11. OPEN LIMIT LED (green) the
led is very helpful during installation.
It illuminates and flashes when the
door is opening and remains steady
on when the open limit position has
been reached.
12. AUTO CLOSE TIME button is
used to adjust the auto close time.
While holding in the auto close but-
ton and then pressing the open but-
ton the time is increased. Each
press will increase the time by 5
seconds.
button will decrease the time.
13. CLOSE LIMIT LED (red) the led
is very helpful during installation. It
direction.
illuminates and flashes when the
door is closing and remains steady
on when the close limit position has
been reached.
14. MINUS (-) (RED) button is used
during installation to help set the
receiver
close limit position. Pressing and
holding this button will move the
door in
Movement stops when the button is
released.
operations of the
Pressing the close
the close direction.
5
15. DOOR STATUS LED (Yellow)
16. DOOR CODE (BLUE)button is
used for storing or erasing the
transmitter button you wish to use to
command the door to open, stop or
close.
17. CODING LED light flashes
when a code is being stored or
when a transmitter
pressed.
18. LIGHT CODE button is used for
storing or erasing the
transmitter button (code) you wish
to use to switch the courtesy light on
the opener on or off.
19. SET (ORANGE) button is used
during the installation phase togeth-
er with the Open and Close buttons
to set the door limit positions. The
Set button is also used to re-ini-
tialise the Opener.
20. .
Terminal Block. 24V PWR is used
to power devices such as photo
electric beams.
PE (Input) for photo electric beam
for safety and auto-close function.
LGT (Input) allow hard wired
external trigger for the opener's
courtesy light.
O/S/C INPUT is used for the
connection of a wired switch
(momentary contact). This switch
can then be used to open, stop or
close the door. Install the wall switch
in a location where the switch is out
of reach of children and the garage
door is visible.
