- Page 1 ® GDO-9V1 SecuraLift Overhead Garage Door Opener I I n n s s t t a a l l l l a a t t i i o o n n I I n n s s t t r r u u c c t t i i o o n n s s...
-
Page 2: Table Of Contents
Automatic Technology Australia Pty Ltd Garage Door Opener in accordance with these installation instructions. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS Warning - It is vital for the safety of persons to follow all instructions. Failure to comply with the following Safety Rules may result in serious personal injury and/or property damage. The unit should be installed so that it is protected Caution: If your garage has no pedestrian entrance from the elements. -
Page 4: Opener Features
FEATURES Thank you for purchasing the ATA ISS (INTELLIGENT SAFETY VACATION MODE GDO-9 Automatic Garage Door OBSTRUCTION SYSTEM) A transmitter can be programmed to Opener. This opener is designed to Whilst performing a close cycle the block out all other transmitters that suit sectional overhead and one door will automatically reverse if it... -
Page 5: Operating Controls
OPERATING CONTROLS P. E. SHUNT. The shunt has to 15. DOOR STATUS LED (Yellow) 10. FORCE MARGIN SET Button be removed when connecting a The obstruction force pressure is Photo Electric Beam. set automatically by the opener 16. DOOR CODE (BLUE)button is during installation. - Page 6 OPERATING CONTROLS FIG. 1 P.E. SHUNT OPEN LIMIT LED 24V POWER INPUT CONNECTOR AUTO CLOSE TIME BUTTON 10 AMP FUSE CLOSE LIMIT LED SBY-3 BATTERY BACK UP CONNECTOR MINUS ( - ) (RED) BUTTON MOTOR CONNECTOR STATUS LED OPERATE (YELLOW) BUTTON DOOR CODE (BLUE) BUTTON PLUS (+) (GREEN) BUTTON CODE SET LED...
-
Page 7: Kit Contents
KIT CONTENTS FIG. 2 GDO-9V1 AUTO OPENER CH P/N 00090 ITEM QUANTITY GDO-9 SECTIONAL DOOR OPENER DRIVE UNIT------------------------------------------------------1 EASY ACCESS TRANSMITTER EAT-1 (NOT INCLUDED IN SOME MODELS) -----------------1 KEY RING TRANSMITTER PTX-4 PACK--------------------------------------------------------------------1 (pack includes two keyring transmitters two batteries and one wall mount bracket for ptx4 transmitter) C-RAIL PACK--------------------------------------------------------------------------------------------------------1 DOOR ATTACHMENT ARMS------------------------------------------------------------------------------------2 ACCESSORY PACK------------------------------------------------------------------------------------------------1... - Page 8 KIT CONTENTS ITEMS FIG. 3 one piece c-rail assembly See fig 3 Note chain in one piece rail has been tensioned by the factory Do not adjust the tension of the chain IMPORTANT NOTE If modification to the track length required,adjustment must be made only from power head side.
-
Page 9: Installation
C-RAIL ASSEMBLY FIG. 6 Step 1 Unpack and assemble the C -rail as shown above in fig 6... - Page 10 C-RAIL ASSEMBLY Step 2 FIG. 7 Locate and insert the shaft of drive unit into sprocket as shown in fig 7 Step 3 FIG. 8 Fix the two track brackets as shown in fig 8 fix with four screws supplied in accessory pack...
-
Page 11: Determine Door Type
DETERMINE THE DOOR TYPE Step 4 FIG. 9 Determine which type of garage door you have as illustrat- ed below. (Fig. 9 - 11). l For a sectional (panel) door on tracks (Fig. 9) proceed with the installation from Step 5. l For a one piece door on tracks (Fig. -
Page 12: Mounting - Track Type Door
MOUNTING OPENER FOR TRACK TYPE DOOR STEP 5 FIG. 12 Open the door and find the highest point of travel of the top door panel. Using a level, transfer this height to the wall above the door (Fig. 12) and mark a line 60mm above it. -
Page 13: Mounting - Spring Loaded Door
MOUNTING OPENER FOR SPRING LOADED DOOR STEP 9 FIG. 16 Determine the centre of the door and mark this location on the wall above and on top of the door. Then draw two (2) lines 21.5mm on each side of the centre point. (Fig. -
Page 14: Mounting Door Bracket & Arms
MOUNTING DOOR BRACKET AND ARMS STEP 12 FIG. 19 With the centre point of the door located, mark a line through the centre of the wall bracket onto the header wall (above the door). Using the bracket as a template mark a minimum of two holes and drill with appropriate size bit. -
Page 15: Easy Access Transmitter
EASY ACCESS TRANSMITTER EASY ACCESS TRANSMITTER FIG. 22 The Easy Access Transmitter is prepared ready for use with the battery pre-installed. Before the transmitter can be operational, the transmitter code has to be stored into the openers memory. To store the code refer to Step 18.1 on page 19. -
Page 16: Programming The Opener
SETTING LIMITS STEP 15 FIG. 26 SETTING TRAVEL LIMITS POSITIONS METHOD ONE: VIA THE CONTROL PANEL IMPORTANT NOTE: The OPERATE button will not function until the open and close limits positions are set. Remove the controls cover to access the controls panel as shown in fig 26 15.1 SETTING LIMITS POSITIONS NOTE: The door and shuttle must be engaged into the... -
Page 17: Setting Travel Limits - Transmitter
SETTING LIMITS STEP 16 FIG. 29 SETTING TRAVEL LIMIT POSITIONS METHOD TWO: VIA THE TRANSMITTER IMPORTANT NOTE: The OPERATE button will not function until the open and close limits positions are set. Remove the controls cover to access the controls panel as shown in fig 26 page 16 16.1 CODING TRANSMITTER FOR SETTING LIMITS 1. -
Page 18: Safety Obstruction Force Test
SETTING SAFETY OBSTRUCTION FORCE STEP 17 FIG. 32 SAFETY OBSTRUCTION TEST Please take care when testing the Safety Obstruction Force. Excessive force may cause SERIOUS PERSON- AL INJURY and/or PROPERTY DAMAGE can result from failure to follow this warning. 17.1 TESTING CLOSE CYCLE 1. -
Page 19: Coding Transmitters
CODING TRANSMITTERS STEP 18 FIG. 34 SETTING TRANSMITTERS CODES Make sure to connect the battery to the transmitters. The memory in the openers receiver can store up to 24 different remote control transmitters. 18.1 STORING THE TRANSMITTERS CODE 1. Press and hold the Door Code button (Fig. 34). 2. -
Page 20: Storing Transmitter From Remote Loc
CODING TRANSMITTERS STEP 19 FIG. 37 STORING TRANSMITTER(S) FROM A REMOTE LOCATION Using this method you don’t need to have access to the control panel on the Door Opener. However, you do need a transmitter that is pre coded to the controller’s receiver. -
Page 21: Accessories
PE BEAM AND AUTO CLOSE STEP 21. FIG. 39 FITTING THE SAFETY PHOTO ELECTRIC BEAM SENSOR (OPTIONAL) REMOVE Locate the Photo Electric Beam (P.E.) normally closed PE SHUNT contact type in a strategic location within doorway. We recommend 150mm above the floor level and as close as possible to the door opening, inside the garage. -
Page 22: Battery Backup Installation
BATTERY BACKUP INSTALLATION FIG. 42 WIRING DIAGRAM 4. CONNECT 1. REMOVE SCREWS & SWING COVER TO OPEN BATTERY ASSEMBLY (#01660) 5. CLOSE COVER AND RE-SECURE WITH SCREW 3. MOUNT BATTERY AND SECURE WITH ITEM 4 & 10 2. CONNECT WIRES AS SHOWN REFER TO WIRING DIAGRAM PARTS LIST ITEM... -
Page 23: Final Set
FINAL SET UP 23. SETTING OF COURTESY LIGHT TIME FIG. 43 The preset courtesy light time on the door opener is 3 minutes. This time can be changed by the following: 1. Press in and hold both the Auto Close Time button and Force Margin Set button (Fig. -
Page 24: Parameter
PARAMETERS DOOR STATUS INDICATORS CLOSE LED DOOR STATUS DOOR OPENER STATE OPEN LED GREEN BEEPER LED YELLOW OPEN CLOSE OPENING FLASHING CLOSING FLASHING DOOR TRAVEL STOPPED FLASHING FLASHING DOOR OBSTRUCTED WHEN OPENING FLASHING BEEPS WHILE DOOR OBSTRUCTED WHEN CLOSING FLASHING DOOR IS MOVING ALTERNATING ALTERNATING... -
Page 25: System Specification
DEFAULT SETTINGS AND SPECIFICATIONS FACTORY DEFAULT SETTINGS DEFAULT STEP MAXIMUM MAXIMUM MOTOR RUN TIME 25 Secs. — — COURTESY LIGHT TIME 3 Mins. 10 Secs. 4 Mins. OBSTRUCTION FORCE MARGIN AUTO CLOSE TIME 0 Secs. 1 Sec. 4 Mins. TECHNICAL SPECIFICATIONS POWER SUPPLY 230V - 240V AC 50Hz TRANSFORMER RATING............24V DC... -
Page 26: Trouble Shooting Guide
TROUBLE SHOOTING SYMPTOM POSSIBLE CAUSE REMEDY Switch on mains power. Door will not operate. Mains power not switched on. Remove obstruction. Door is obstructed. Unlock door or remove jam. Door is locked or motor jammed. Door requires service/repair by qualified Door tracks/hardware damaged. -
Page 27: Parts List
SPARE PARTS LIST... -
Page 28: Warranty
Trade Practices Act 1974 (Cth). 2. Subject to all of the matters set out below, Automatic Technology Australia Pty Ltd (“ATA”) warrants: (a) swing and sliding gate opener drive units for twelve (12) months or 2500 cycles, whichever occurs first;...
