EASY ACCESS TRANSMITTER

The Easy Access Transmitter is prepared ready for use
with the battery pre-installed. Before the transmitter can
be operational, the transmitter code has to be stored into
the openers memory. To store the code refer to Step 18.1
on page 19.
REMOVING THE COVER TO REPLACE BATTERY
1. Rotate the cover Clockwise to CLOSE
2. Rotate the cover Anti-clockwise to OPEN
REMOVING THE BATTERY
(Battery Type: 3V Lithium Battery CR1220).
Use a non-metallic object (e.g pen) to remove the battery.
Gently lever the battery out of the holder, taking care to
not damage the circuit board. (Fig. 24)
WARNING
Metallic objects used to remove the battery may damage
the circuit board or the battery.
REPLACING THE BATTERY
Make sure that positive (+) side is facing up. Place one
side of the battery into the holder (Fig. 25), then press the
battery in and down firmly until it clicks into a flat position.
Note: The length of the manual release cord is user
adjustable. Simply slide the plastic toggle along the cord
to achieve the desired length. Adjust the length of the
cord so that it can be easily reached by an adult of
average height (ie. less than 1.8m tall).
EASY ACCESS TRANSMITTER
Note: Positive (+) side up
15
PRESS BUTTON
+
ROTATE
+
FIG. 22
FIG. 23
FIG. 24
FIG. 25
