T S
ECHNICAL PECIFICATIONS
This section lists the technical specifications for the OfficeConnect
Secure Router.
Interfaces
Cable or DSL modem connection - one 10/100 Mbps Ethernet
port (10BASE-T/100BASE-TX) with Auto-MDI/MDIX.
LAN connection - four 10/100 Mbps Ethernet ports
(10BASE-T/100BASE-TX) with Auto-MDI/MDIX.

Operating Temperature

0 °C to 40 °C (32 °F to 105 °F)
Power
7 W power dissipated
Humidity
0 % to 90 % (non-condensing) humidity
Dimensions
Width = 220 mm (8.7 in.)
Depth = 135 mm (5.3 in.)
Height = 36 mm (1.4 in.)
Weight
Approximately 537 g (1.18 lbs)

VPN Tunnels

Two
Standards
Functional:ISO 8802/3
IEEE 802.3
Safety:UL 60950, EN 60950
CSA 22.2 #60950
IEC 60950
EMC:EN 55022 Class B
EN 55024
†
AS/NZS 3548 B
†
FCC Part 15 Class B
†
ICES-003 Class B
†
VCCI Class B
CNS 13438 Class A
Environmental:EN 60068 (IEC 68)
†
Category 5 screened cables must be used to ensure compliance
with the Class B requirements of this standard. The use of
unscreened cables (Category 3 or Category 5) complies with the
Class A requirements.
Category 5 cables must be used if you are connecting to
100 Mbps devices.
*See "Safety Information"
operation.
85
†
*
on page 87 for conditions of
