The connections made by L2TP over IPSec will appear to come
from these addresses. The addresses must be in a continuous
range.
In the Address Pool for PPTP and L2TP clients field enter:
The first LAN address you wish to reserve for L2TP over IPSec
in the First Remote IP Address field.
The last LAN address you wish to reserve for L2TP over IPSec
in the Last Remote IP Address field.
If both PPTP and L2TP over IPSec modes are selected, then the
Address Pool is the same for both clients.
These addresses must be within the Router's LAN subnet and
must not form part of the DHCP pool.
Click Apply to save your changes.
5
PPTP Configuration
To set up the Router for PPTP you must allocate IP addresses
from the Router's LAN for use with PPTP. The connections made
by PPTP will appear to come from these addresses. The addresses
must be in a continuous range.
In the Address Pool for PPTP and L2TP clients field enter:
The first LAN address you wish to reserve for PPTP clients in
the First Remote IP Address field.
and
The last LAN address you wish to reserve for PPTP clients in
the Last Remote IP Address field.
If both PPTP and L2TP over IPSec modes are selected, then the
Address Pool is the same for both clients..
These addresses must be within the Router's LAN subnet and
must not form part of the DHCP pool.
Click Apply to save your changes.

Viewing VPN Connections

The VPN Connections Screen shows information about the IPSec,
L2TP over IPSec, and PPTP connections made by the Router. It
also allows you to add, delete, edit and temporarily disable these
connections.
Figure 60 VPN Connections Screen
60
