I
NSTALLING THE

Introduction

This chapter will guide you through a basic installation of the
OfficeConnect Secure Router, including:
Connecting the Router to the Internet.
Connecting the Router to your network.

Positioning the Router

You should place the Secure Router in a location that:
is conveniently located for connection to the cable or DSL
modem that will be used to connect to the Internet.
allows convenient connection to the computers that are to be
connected to the four LAN ports on the rear panel.
allows easy viewing of the front panel LED indicator lights,
and access to the rear panel connectors, if necessary.

Safety Information

WARNING: Please read the "Important Safety Information"
section before you start.
VORSICHT: Bitte lesen Sie den Abschnitt "Wichtige
Sicherheitsinformationen" sorgfältig durch, bevor Sie das Gerät
einschalten.
AVERTISSEMENT: Veuillez lire attentivement la section
"Consignes importantes de sécurité" avant de mettre en route.
R
OUTER
When positioning your Router, ensure:
It is out of direct sunlight and away from sources of heat.
Cabling is away from power lines, fluorescent lighting fixtures,
and sources of electrical noise such as radios, transmitters and
broadband amplifiers.
Water or moisture cannot enter the case of the unit.
Air flow around the unit and through the vents in the side of
the case is not restricted. We recommend you provide a
minimum of 25mm (1in.) clearance.

Using the Rubber Feet

Use the four self-adhesive rubber feet to prevent your Router
from moving around on your desk or when stacking with flat top
OfficeConnect units. Only stick the feet to the marked areas at
each corner of the underside of your Routerl.

Using the Stacking Clip

The stacking clip allows you to stack your OfficeConnect units
together neatly and securely.
CAUTION: You can stack up to a maximum of four units. Smaller
units must be stacked above larger units.
To fit the clip:
Place your unit on a flat surface.
1
Fit the clip across the top of the unit, as shown in
2
Figure 5 (picture 1), ensuring that the longer sections of the
fastening pieces are pointing downwards.
Align the fastening pieces over the slots found on each side of
3
the unit.
15
