Viewing The Summary - 3Com OfficeConnect User Manual

Figure 24 DHCP Server Setup Screen
3Com recommends that you activate the DHCP server and leave
it at the default values unless you already have a DHCP Server on
your network.
To activate the DHCP Server option, select Enable the DHCP
server with the following settings:. The DHCP server will
default to the addresses 192.168.1.100 to 192.168.1.200 if
the IP address of the Router has been left at the default
192.168.1.1.
The Setup Wizard suggests a DHCP server address range that is
valid for the LAN settings entered. If the defaults are used it will
be 100 - 200. The suggested range will vary depending on the
LAN settings entered in the LAN IP Address screen.
To disable DHCP, select Do not enable the DHCP server.
Click Next when you have finished.

Viewing the Summary

When you complete the Setup Wizard, a configuration summary
will display. See Figure 25
information of the Router and click Finish to save your settings
and restart the Router.
Figure 25 Configuration Summary Screen
3Com recommends that you print the Configuration Summary
screen for your records.
If you have changed the IP address of your Router your computer
will need to change its IP address to communicate with the
Router. Reboot your computer once the Router has restarted to
get a new address.
31
below. Verify the configuration
