Click Apply to save your changes or Close to return without
saving. When you have created a user account the user will need
to know in order to enable connection.
PPTP Connections
If you have selected PPTP as a Tunnel Type, enter the following:
Username — This is the username that the remote VPN client
will use to connect.
Password — The Password that the user will need to supply
to connect. (Figure 64)
When you have created a user account the user will need to
know the User Name and Password you have given them.
Figure 64 PPTP Connections
The screens to edit and add a PPTP user contain the same fields.
Click Apply to save your changes or Close to return without
saving.

Editing IPSec Routes

The IPSec Routes tab is only displayed when IPSec Enabled is
selected on the VPN Mode screen. This screen allows you to add
and replace networks in the existing IPSec Route. See
To do this:
1 Select edit to display the Edit Route screen.
Click in the table and add a new Network and Subnet Mask
2
entry.
Leave the Negotiate all subnets whenever tunnel is triggered
3
check box blank, unless the remote subnet cannot open the
connection, and needs to try more than one subnet.
4 Click Apply to save your changes or Close to return without
saving.
The gateway for a remote network must also be set to use the
VPN tunnel to access your local network. Therefore, if you
include a subnet for a remote network in your IPSec route then
the remote network must also include your subnet in its IPSec
route also.
66
Figure 65
(Figure 66).
