Static IP Mode
To setup the Router for use with a static IP address connection,
use the following procedure:
Figure 18 Static IP Mode Screen
1 Enter your IP Address in the IP Address text box.
2 Enter your subnet mask in the Subnet Mask text box.
3 Enter your ISP Gateway address in the Internet (ISP) Gateway
Address text box.
Enter your primary DNS address in the Primary DNS Address text
4
box.
5 If your ISP provides a secondary DNS address, enter it in the
Secondary DNS Address text box, otherwise leave the box blank.
Click Next to continue.
6
Dynamic IP Address Mode
To setup the Router for use with a dynamic IP address
connection:
Figure 19 Hostname Screen
1 If your ISP requires the addresses of a Primary and Secondary
DNS Server then enter them in the fields labelled Primary DNS
Address and Secondary DNS Address.
If your ISP does not require one of the fields to be filled in then
leave it blank.
If your ISP requires you to supply a host name enter it in the Host
2
Name box, otherwise leave the box blank.
3 Click Next to continue to the Clone MAC Address screen, shown
in Figure 20 below.
