3Com OfficeConnect User Manual page 28

Figure 20 Clone MAC Address Screen
If your ISP requires an assigned MAC address, select the
4
appropriate radio button:
Yes, please clone the MAC address from the PC I'm currently
using if the computer you are using now is the one that was
previously connected directly to the cable or DSL modem.
Yes, I would like to enter a MAC address manually and
manually enter the values for a MAC address if the computer
you are using now was not previously connected directly to
the cable or DSL modem.
Otherwise select No.
5 Click Next to continue
Continue at "Choosing your LAN Settings"
1
2
3
on page 30.
28
PPPoE Mode
To setup the Router for use with a PPP over Ethernet (PPPoE)
connection, use the following procedure:
Figure 21 PPPoE Screen
Enter your PPP over Ethernet user name in the PPPoE User Name
text box.
Enter your PPP over Ethernet password in the PPPoE Password
text box.
If your ISP does not require one of the fields to be filled in then
leave it blank.
If your ISP requires you to supply a PPPoE service name, enter it
in the PPPoE Service Name text box.
