EXTRA 260.
THROTTLE SERVO ARM
INSTALLATION.
) Install adjustable servo connector in
1
the servo arm.
2) Install the pushrod throttle.
Engine - 2 stroke:
Throttle.
Engine - 4 stroke:
Throttle.
12
Switch.
Adjustable Servo
connector.
Servo arm.
Instruction Manual.
INSTALLING HORIZONTAL FIN.
1) Remove the covering at the rear tail
root of horizontal fin as picture shown below.
2) Sand the aluminium tube using
sandpaper. This will improve the bond of the
epoxy to the cardboard horizontal fin.
Coat both sides of one half of the aluminium
tube with 30 minute epoxy. Next, pour some
epoxy into the cardboard horizontal fin. Use
enough epoxy to fill any gaps.
3) Insert aluminium tube into the
cardboard of fuselage.
4) Slide the two horizontal fin halves
together and carefully align them at
possition on the fuselage. Wipe away any
excess epoxy using paper towels.
the
