Installation Manual
H3C SecPath F100-C Firewall

Figure 4-3 Select serial interface

2) Set the serial interface
The [Settings] tab appears as shown in Figure 4-4, and set the
serial interface parameters as follows:
Bits per second = 9600
Data bits = 8
Parity = None
Stop bits = 1
Flow control = None
Click <OK> and the HyperTerminal dialog box appears.
Chapter 4 Starting and Configuring
the H3C SecPath F100-C
4-3
