Caution:
Upgrade the H3C SecPath F100-C software under the guide of
support technicians. When upgrading, make the Boot ROM software
match the application program.
5.2 Upgrading Application Programs and
Boot ROM program Using XModem
You can use XModem to upgrade the software through the
console port even without setting up a configuration environment.
I. Upgrading application program
Step 1: Enter the Boot menu and select 1 to download an
application program using XModem. The following download speeds
are available for the H3C SecPath F100-C:
WARNING: The operation is to update the Boot ROM.
Please choose your download speed:
1: 9600 bps
2: 19200 bps
3: 38400 bps
4: 57600 bps
5: 115200 bps
6: Exit and reboot
Enter your choice(1-6):
It may result in booting failure.
Chapter 5 Maintaining the H3C
5-4
SecPath F100-C
