Installation Manual
H3C SecPath F100-C Firewall
security (IPsec) VPN, generic routing encapsulation (GRE) VPN and
dynamic VPN, to access remote branch office into the headquarters.
H3C SecPath
management system (BIMS) feature to automatically upgrade the
configuration file and application programs, and the VPN manager
function to configure and deploy VPNs.
H3C SecPath F100-C provides basic routing features, including
the routing information protocol (RIP), open shortest path first (OSPF),
routing policy, and policy routing, as well as abundant QoS features,
such as traffic policing, traffic shaping, and queue scheduling.

1.2 Hardware Features

1.2.1 Hardware Features of the H3C SecPath F100-C

I. Appearance
( 1 )
(1) Ethernet LED LAN3
(3) Ethernet LED LAN1
(5) WAN LED
(7) Power LED (PWR)

Figure 1-1 Front panel of the H3C SecPath F100-C

F100-C
( 4 ) ( 5 ) ( 6 ) ( 7 )
( 2 )
( 3 )
Chapter 1 Product Overview
supports the
(2) Ethernet LED LAN2
(4) Ethernet LED LAN0
(6) System LED (SYS)
1-2
branch intelligent
