INSTRUMENTS AND INDICATORS

KEY
1) Rev counter
2) Red line light
3) Green direction indicator light (
4) Blue high beam light (
5) Amber "stand down" light ( )
6) Amber low fuel light ( )
7) Red immobilizer light (
1 2
11
)
)
) (where immobilizer system is fitted)
3 4 5 6
10
8) Green neutral light ( )
9) Multifunction digital display (coolant temperature - clock -
battery voltage - lap timer - engine oil pressure diagnostics
( )
10) Red general warning light (
11) Multifunction computer programming buttons (+, Trip V, -)
7
8
9
)
use and maintenance RSV 1000 R - RSV 1000 R FACTORY 17
