ARRANGEMENT OF THE MAIN ELEMENTS
5
4
3
2
1
KEY
1) Left side fairing
2) Adjustable steering damper
3) Headlight left lamp
4) Front fairing
5) Left rear-view mirror
6) Clutch fluid reservoir
use and maintenance RSV 1000 R - RSV 1000 R FACTORY
12
6 7
21 20 19
7) Engine oil filter
8) Left side panel
9) Rider seat
10) Battery
11) Main fuse carrier (30 A)
12) Passenger seat lock
glove/tool kit compartment
RSV R
8 9 10 11
18 17 16 15
13) Passenger left footrest
(snaps closed/open)
14) Drive chain
15) Rear swinging arm
16) Rider left footrest
17) Side stand
18) Gear shift lever
12
13
14
19) Engine oil tank
20) Engine oil level
21) Engine oil tank cap
