  • Page 1 SYNTHESIS SDP-40 DIGITAL SURROUND PROCESSOR/CONTROLLER USER GUIDE...
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus, (including amplifiers) that produce heat.
  • Page 3 © 2003 JBL Synthesis. All rights reserved. This document should not be construed as a commitment on the part of JBL Synthesis. The information it contains is subject to change without notice. JBL Synthesis assumes no responsibility for errors that may appear within this document.

  • Page 4: Table Of Contents

    Introduction Introduction Important Safety Instructions ....iv Wichtige Sicherheitsanweisungen ....iv Instrucciones importantes de seguridad .
  • Page 5 SDP-40 Section 3: SETUP (continued) TRIGGER SETUP ....... . . 3-48 LOCK OPTIONS .

  • Page 6: Introduction

    Introduction ENGLISH IMPORTANT SAFETY INSTRUCTIONS Save these instructions for later use. • Follow all instructions and warnings marked on the unit. • Always use with the correct line voltage. Refer to the manufacturer’s operating instructions for the power requirements. Be advised that different operating voltages require the use of a different line cord and/or attachment plug.

  • Page 7: Es Instrucciones Importantes De Seguridad

    SDP-40 ESPAÑOL INSTRUCCIONES IMPORTANTES DE SEGURIDAD Guarde esta instrucciones para uso posterior. • Utilice siempre el voltaje correcto. Diríjase a las instrucciones de operación del fabricante para obtener las especificaciones de potencia. Esté al tanto de que voltajes de operación distintos requieren el uso de cables y/o enchufes distintos.

  • Page 8: It Importanti Norme Di Sicurezza

    Introduction ITALIANO IMPORTANTI NORME DI SICUREZZA Conservare le presenti norme per l’utilizzo futuro. • Osservare tutte le istruzioni e le avvertenze apposte sull’unità. • Utilizzare esclusivamente con la tensione di rete corretta. Consultare le istruzioni operative fornite dal fabbricante per i dati riguardanti la tensione e l’assorbimento di corrente. Potrebbe essere necessario l’uso di cavi di rete e/o di spine diverse a seconda della tensione utilizzata.

  • Page 9: Dk Vigtig Information Om Sikkerhed

    SDP-40 DANSK VIGTIG INFORMATION OM SIKKERHED Gem denne vejledning til senere brug. • Følg alle anvisninger og advarsler på apparatet. • Apparatet skal altid tilsluttes den korrekte spænding. Der henvises til brugsanvisningen, der indeholder specifikationer for strømforsyning. Der gøres opmærksom på, at ved varierende driftsspændinger kan det blive nødvendigt at bruge andre lednings- og/eller stiktyper.

  • Page 10: No Viktig Informasjon Om Sikkerhet

    Introduction NORSK VIKTIG INFORMASJON OM SIKKERHET Ta vare på denne veiledningen for senere bruk. • Følg alle anvisningene og advarslene som er angitt på apparatet. • Apparatet skal alltid anvendes med korrekt spenning. Produktbeskrivelsen inneholder spesifikasjoner for strømkrav. Vær oppmerksom på at det ved ulike driftsspenninger kan være nødvendig å...

  • Page 11: Us Unpacking And Inspection

    SDP-40 Unpacking and Inspection After unpacking the unit, save all packing materials in case the unit ever needs to be shipped. Thoroughly inspect the modules and packing materials for signs of damage. Report any damage to the carrier at once; report equipment malfunction to the dealer. Auspacken und Überprüfung Bewahren nach...

  • Page 12: Section 1: Getting Started

    About the SDP-40 ........1-2 Highlights •...

  • Page 13: About The Sdp-40

    Getting Started ABOUT THE SDP-40 Thank you for purchasing the SDP-40 Digital Controller, a reference- quality, 12-channel audio and video control center with independent zone monitoring to provide control of input source selection in three zones at the same time. As flexible as it is powerful, the SDP-40 includes 12 configurable inputs, each of which can be assigned to its 13 digital audio, 8 analog audio, 5 composite video, 8 S-video, or 4 component video input connectors.

  • Page 14: Highlights

    SDP-40 Complementing its pristine audio performance, the SDP-40 includes two broadcast-quality video switchers. An ultra-wide bandwidth component video switcher accepts analog component or RGB video signals, while a composite and S-video switcher accepts high-quality NTSC, PAL, or SECAM video signals. The component video switcher can pass High-Definition TV (HDTV) and Standard-Definition TV signals.

  • Page 15: Installation Considerations

    Getting Started INSTALLATION CONSIDERATIONS The SDP-40 requires special care during installation to ensure optimal performance. Pay particular attention to the bulleted items that begin below and to other precautions that appear throughout this user guide. • Install the SDP-40 on a solid, flat, level surface such as a table , shelf, or in a standard 19-inch equipment rack using the enclosed rack-mount kit.

  • Page 16: Remote Control Battery Installation

    SDP-40 REMOTE CONTROL BATTERY INSTALLATION The remote control requires two AA batteries that should be replaced as needed. It is recommended to use Alkaline batteries, which last longer without leaking. When the batteries are low on power, the remote control enters a low-voltage condition that prevents it from operating the SDP-40.
  • Page 17 Front Panel Overview ....... . . 2-2 Rear Panel Overview ........2-5 Remote Control Overview .

  • Page 18: Front Panel Overview

    Basic Operation FRONT PANEL OVERVIEW Red LED Blue LED IR Receiver Amber LED...
  • Page 19 SDP-40 1. Standby Button Activates and deactivates standby mode when the SDP-40 is powered on with the rear panel power switch. The standby button performs no function when the SDP-40 is powered off with the rear panel power switch. When standby mode is activated, pressing the standby button deactivates standby mode and activates the SDP-40 including all zones that were activated during the previous operating session.
  • Page 20 Basic Operation Front Panel Overview The amber Mute button LED lights whenever mute is activated, whether activated automatically or manually. For instance, the SDP-40 briefly activates mute when changing input sources or listening modes. To use the volume knob to adjust Main Zone volume level: 1.

  • Page 21: Rear Panel Overview

    SDP-40 8. Main Zone Off Button Deactivates the Main Zone. 9. Zone 2 Input Selection Buttons Selects the input in Zone 2. When an input is selected, an amber LED lights on the corresponding input selection button. When Zone 2 is deactivated, pressing a Zone 2 input selection button activates Zone 2 and selects the corresponding input.
  • Page 22 Basic Operation...
  • Page 23 SDP-40 When a 5.1-channel analog source is present in the Main Zone and the INPUT SETUP menu ZONE2 IN or RECORD IN param- eter is set to DMIX, only the (L) and (R) input signals are sent to the Zone 2 or Record Zone audio output connectors.
  • Page 24 Basic Operation Rear Panel Overview (continued from page 2-7) 10.Main Zone Video Output Connectors Provide video output in the Main Zone. Two composite video connectors, two S-video connectors, and one component video connector (BNC) are available. The composite and S-video connectors labeled 1 (OSD) incorporate the on-screen display.

  • Page 25: Remote Control Overview

    SDP-40 REMOTE CONTROL OVERVIEW The SDP-40 remote control provides full operation of the SDP-40, performing commands such as menu navigation that are not available from the front panel. The command matrix that begins on page 2-14 indicates the commands remote control buttons perform when each command bank is activated.

  • Page 26: Main Menu

    Basic Operation MAIN MENU The MAIN MENU represents the beginning of the menu structure. It can be used to open the three main menu branches: MODE ADJUST, AUDIO CONTROLS, and SETUP. Button Navigation Command(s) • When a menu is open, pressing the MENU button closes the menu structure. MENU •...

  • Page 27: Menu Item Selection

    SDP-40 MENU ITEM SELECTION The remote control arrow buttons must be used to select menu items. MAIN MENU SETUP MODE ADJUST INPUTS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS To select a menu item on the open menu: 1.

  • Page 28: Command Bank Activation

    Basic Operation To select a parameter setting with a horizontal graph: 1. When the horizontal graph appears, press the arrow buttons to increase and decrease the setting in designated increments. The current setting appears at the right of the parameter name on the on-screen and front panel displays. 2.
  • Page 29 SDP-40 MAIN ZONE SHIFT DVD-1 DVD-2 GAME TAPE TUNER MODE BLUE STAT MUTE MENU 7 / 5 2 CH MUSIC Button Main Zone Zone 2 Activates and deactivates standby mode when the SDP-40 is powered on with the rear panel power switch.
  • Page 30 Basic Operation MAIN ZONE SHIFT DVD-1 DVD-2 GAME TAPE TUNER MODE BLUE STAT MUTE MENU 7 / 5 2 CH MUSIC 2-14 Button Main Zone Zone 2 Selects the SAT input Selects the SAT input SA T for the Main Zone. for Zone 2.
  • Page 31 SDP-40 MAIN ZONE SHIFT DVD-1 DVD-2 GAME TAPE TUNER MODE BLUE STAT MUTE MENU 7 / 5 2 CH MUSIC Button Main Zone Zone 2 Toggles the FRONT Sets Zone 2 volume PANEL DISPLAY menu level to -15dB. STATUS parameter between ALWAYS OFF and its current setting.
  • Page 32 Basic Operation MAIN ZONE SHIFT DVD-1 DVD-2 GAME TAPE TUNER MODE BLUE STAT MUTE MENU 7 / 5 2 CH MUSIC 2-16 Button Main Zone Zone 2 Displays the Main Displays the Zone 2 S TA T Zone two-line status two-line status for 2 for 2 seconds.
  • Page 33 SDP-40 MAIN ZONE SHIFT DVD-1 DVD-2 GAME TAPE TUNER MODE BLUE STAT MUTE MENU 7 / 5 2 CH MUSIC Button Main Zone Zone 2 Selects the THX mode Reserved for future family for the current expansion. input source. Selects the Dolby Reserved for future mode family for the expansion.

  • Page 34: Understanding The Zones

    Basic Operation UNDERSTANDING THE ZONES The SDP-40 features three zones of operation, called the Main Zone, Zone 2, and the Record Zone. The Main Zone controls audio and video sources in the primary listening space. Zone 2 controls audio and video sources in the secondary listening space. And, the Record Zone controls audio and video sources sent to recording devices or to a third listening space.

  • Page 35: Status Menus

    SDP-40 Record Zone Two-Line Status Opens on the on-screen and front panel displays whenever the SDP-40 detects a Record Zone status change. The Record Zone two-line status indicates the current input, input source, and volume level selected in the Record Zone. The ON-SCREEN DISPLAY menu STATUS parameter can be used to control the length of time for which the two-line status appears on the on-screen and front panel displays.

  • Page 36: Ch Status

    Basic Operation 2CH STATUS %!D STATUS INPUT INPUT MODE MODE INPUT TYPE CHANNELS SAMPLE RATE BIT RATE EX ENCODED SL SR SB LFE 5.1 ANALOG STATUS 5.1a BYPASS STATUS INPUT INPUT MODE MODE INPUT TYPE INPUT TYPE SAMPLE RATE R SL SR page, pressing the STAT button again will close the menu.

  • Page 37: D Status

    SDP-40 D STATUS •Provides information about Dolby Digital sources. • Includes L, C, R, SL, SR, and LFE level meters. Parameter Possible Settings INPUT The current input MODE The current listening mode CHANNELS 3/2.1, 3/2, 3/1, 2/2, 2/1, 2/0, 1/0 BIT RATE 32 to 640kbps EX ENCODING...

  • Page 38: Analog Status

    Basic Operation 5.1 ANALOG STATUS • Provides information about 5.1-channel analog sources. • Includes L, C, R, SL, SR, and LFE level meters. Parameter Possible Settings INPUT The current input MODE The current listening mode INPUT TYPE ANLG SAMPLE RATE 44.1kHz, 48kHz, 88.2kHz, 96kHz Refer to page 2-24 for status menu parameter descriptions.

  • Page 39: Status Menu Parameter Descriptions

    SDP-40 STATUS MENU PARAMETER DESCRIPTIONS 2.0 ENCODING Indicates whether or not a matrix-encoded source is detected. When the parameter setting is MATRIX, a matrix-encoded source is detected. When the parameter setting is NONE, a matrix-encoded source is not detected. The SDP-40 cannot automatically detect matrix encoding in non-flagged input sources.

  • Page 40: Input Type

    Basic Operation INPUT Indicates the current input (i.e. DVD1). INPUT TYPE Indicates the input source that is present. When the parameter setting is ANLG, an analog audio source is present and the MAIN ADV menu ANALOG BYPASS parameter is set to OFF. When the parameter setting is BYP, an analog audio source is present and the ANALOG BYPASS parameter is set to ON.
  • Page 41 SETUP ..........3-2 INPUT SETUP .

  • Page 42: Inputs

    SETUP SETUP Selecting the MAIN MENU SETUP option opens the SETUP menu shown below, which can be used to configure the SDP-40. MAIN MENU SETUP MODE ADJUST INPUTS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS INPUTS SETUP...

  • Page 43: Input Setup

    SDP-40 LOCK OPTIONS SETUP LOCK OPTIONS Opens the LOCK OPTIONS menu, which can be used to protect MODE ADJUST, AUDIO CONTROLS, and SETUP menu branch parameter settings from accidental changes. Refer to page 3-50 for more information. INPUT SETUP SETUP INPUTS DVD1 DVD1 INPUT SETUP...

  • Page 44: Changing Input Names

    SETUP CHANGING INPUT NAMES SETUP INPUTS DVD1 NAME Selecting the INPUT SETUP menu NAME option opens the INPUT NAME menu shown below, which can be used to customize or restore the factory-default name of the selected input. Factory-default input names correspond to front panel and remote control input selection button labels.
  • Page 45 SDP-40 • Press the arrow button to return to the previous character space. When the cursor is positioned in the first character space, pressing the arrow button will close the EDIT INPUT NAME drop-down menu. 4. When the desired input name has been entered, press the arrow button until the EDIT INPUT NAME drop-down menu closes.

  • Page 46: Assigning Audio & Video Input Connectors

    SETUP ASSIGNING AUDIO & VIDEO INPUT CONNECTORS The SDP-40 has 12 configurable inputs, each of which can be assigned to its 13 digital audio, 8 analog audio, 5 composite video, 8 S-video, or 4 component video input connectors. MAIN MENU SETUP MODE ADJUST INPUTS...
  • Page 47 SDP-40 When no digital audio input connector is assigned, the SDP-40 automatically sets the: • MAIN ADV menu INPUT SELECT parameter to ANALOG • INPUT SETUP menu ZONE2 IN parameter to ANLG • INPUT SETUP menu RECORD IN parameter to ANLG ANALOG IN ANALOG-1 to 8, 5.1 ANLG (6-8), NONE SETUP...
  • Page 48 SETUP Assigning Audio & Video Input Connectors MAIN MENU SETUP MODE ADJUST INPUTS INPUTS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS The DVD1 INPUT SETUP menu is shown here as an example, and will continue to be shown as an example throughout this section. Whenever it appears, any other INPUT SETUP menu may be substituted.

  • Page 49: Level Meters

    SDP-40 AUTO SETUP INPUTS DVD1 ANLG IN LVL AUTO Activates automatic adjustment of 2-channel analog audio input levels. When ON is selected, the SDP-40 automatically monitors and optimizes 2-channel analog audio input levels. When the input signal is too high, the SDP-40 quickly decreases input levels to avoid overload.
  • Page 50 SETUP Assigning Audio & Video Input Connectors VIDEO IN COMPOSITE-1 to 5, S-VIDEO-1 to 8, NONE SETUP INPUTS DVD1 VIDEO IN Opens the VIDEO IN menu shown below, which can be used to assign a composite or S-video input connector for the selected input.

  • Page 51: Selecting Preferred Listening Modes

    SDP-40 MAIN MENU SETUP MODE ADJUST INPUTS INPUTS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS The DVD1 INPUT SETUP menu is shown here as an example, and will continue to be shown as an example throughout this section. Whenever it appears, any other INPUT SETUP menu may be substituted.
  • Page 52 SETUP Selecting Preferred Listening Modes MAIN MENU SETUP MODE ADJUST INPUTS INPUTS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS DVD1 MODE FILM MUSIC 2-CHAN USE LAST 2-CH SETUP INPUTS DVD1 2-CH Opens the 2-CH MODE menu shown above, which can be used to select a preferred listening mode for 2-channel sources.
  • Page 53 SDP-40 was activated the last time a 2-channel source was present. The SDP-40 will not activate a listening mode unless a 44.1 or 48kHz PCM digital source is present. The are not compatible with 88.2 or 96kHz, Dolby Digital, or analog sources.

  • Page 54: Configuring Advanced Input Settings

    SETUP CONFIGURING ADVANCED INPUT SETTINGS MAIN MENU SETUP MODE ADJUST INPUTS INPUTS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS The DVD1 INPUT SETUP menu is shown here as an example, and will continue to be shown as an example throughout this section. Whenever it appears, any other INPUT SETUP menu may be substituted.

  • Page 55: Input Select

    SDP-40 Parameter Possible Settings INPUT SELECT DIGITAL, ANALOG, AUTO ANALOG BYPASS ON, OFF S-VIDEO 16:9 AUTO, OFF S-VIDEO OSD 4:3 ON, OFF COMPONENT OSD ON, OFF INPUT SELECT SETUP INPUTS DVD1 MAIN ADVANCED Controls the interaction of the digital and analog audio input connectors assigned for the selected Main Zone input.
  • Page 56 SETUP Configuring Advanced Input Settings INPUT SELECT Parameter Settings DIGITAL The SDP-40 sends the assigned digital audio input connector to the Main Zone audio output connectors. The SDP-40 ignores the assigned analog audio input connector. Note the following: • When an incompatible digital source is present, the SDP-40 automatically selects the assigned analog audio input connector.
  • Page 57 SDP-40 S-VIDEO OSD 4:3 SETUP INPUTS DVD1 MAIN ADVANCED Controls the on-screen display aspect ratio when the display device is connected to a Main Zone S-video output connector. Aspect ratio refers to the size of the picture or the display device screen. A 4:3 aspect ratio is almost square.
  • Page 58 SETUP Configuring Advanced Input Settings ZONE2 & RECORD IN Parameter Settings DIGITAL The SDP-40 sends the assigned digital The SDP-40 sends the assigned ana- audio input connector to the Zone 2 or log audio input connector to the Zone Record Zone audio output connectors. 2 or Record Zone audio output con- The SDP-40 ignores the assigned analog nectors.

  • Page 59: Record Advanced

    SDP-40 MAIN MENU SETUP MODE ADJUST INPUTS INPUTS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS The DVD1 INPUT SETUP menu is shown here as an example, and will continue to be shown as an example throughout this section. Whenever it appears, any other INPUT SETUP menu may be substituted.
  • Page 60 SETUP Configuring Advanced Input Settings ANLG IN LVL SETUP INPUTS DVD1 RECORD ADVANCED Allows adjustment of analog audio input levels for input signals sent to the Record Zone digital audio output connectors. The SDP-40 applies these adjustments to input signals before passing them to the Record Zone digital audio output connectors.

  • Page 61: Speaker Setup

    SDP-40 SPEAKER SETUP SETUP SPEAKERS Selecting the SETUP menu SPEAKERS option opens the SPEAKER SETUP menu shown below, which can be used to configure the Main Zone audio output connectors for the desired speaker setup. The Main Zone includes 10 unbalanced audio output connectors labeled Front L/R, Center, LFE, Subwoofer L/R, Side L/R, and Rear L/R.
  • Page 62 SETUP Setting Crossover Points (continued from page 3-21) MAIN MENU SETUP MODE ADJUST INPUTS SPEAKERS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS Custom Speaker Setups SETUP SPEAKERS SET CROSSOVERS CUSTOM SETUP Selecting the CROSSOVER SETUP menu CUSTOM SETUP option opens the CUSTOM SETUP menu shown above, which can be used to assign independent crossover points for each Main Zone audio output connector.
  • Page 63 SDP-40 Highpass Filter Highpass filters attenuate low-frequency signals at 24dB per octave. The curves in the graph above indicate the frequency response of each crossover point. From left to right, the curves represent crossover points from 30 to 120Hz. This graph does not include the THX 80Hz crossover point, which attenuates low-frequency signals at 12dB per octave.
  • Page 64 SETUP Setting Crossover Points (continued from page 3-23) MAIN MENU SETUP MODE ADJUST INPUTS SPEAKERS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS SYNTHESIS 7CH Speaker Setups SETUP SPEAKERS SET CROSSOVERS Selecting the CROSSOVER SETUP menu SYNTHESIS 7CH SETUP option opens the SYNTHESIS 7CH SPEAKER SETUP screen shown above, which indicates that pressing the matically configure the Main Zone audio output connectors for a...
  • Page 65 SDP-40 Speaker Setup Parameters SETUP SPEAKERS SET CROSSOVERS CUSTOM SETUP The table below indicates the speaker setup parameters that can be used to configure the Main Zone audio output connectors for the desired speaker setup. These parameters appear on the CUSTOM and SYNTHESIS 7CH SETUP menus.
  • Page 66 SETUP Setting Crossover Points (continued from page 3-25) MAIN MENU SETUP MODE ADJUST INPUTS SPEAKERS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS SUB XOVER SUBWOOFERS L/R FULL MONO 30Hz STEREO 40Hz NONE 50Hz 60Hz 70Hz 80Hz...
  • Page 67 SDP-40 SETUP SPEAKERS SET CROSSOVERS When a SYNTHESIS 7CH speaker setup is selected, the FRONT L/R parameter cannot be adjusted. The SDP-40 automatically applies a 80Hz crossover point to the Front L/R output connectors. CENTER FULL, 30 to 120Hz, THX 80Hz, NONE Assigns a crossover point for the Main Zone audio output connector labeled Center.
  • Page 68 SETUP Setting Crossover Points (continued from page 3-27) MAIN MENU SETUP MODE ADJUST INPUTS SPEAKERS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS REAR L/R FULL, 30 to 120Hz, THX 80Hz, NONE Assigns a crossover point for the Main Zone audio output connectors labeled Rear L/R.
  • Page 69 SDP-40 SUB L/R SETUP SPEAKERS SET CROSSOVERS CUSTOM SETUP Configures the Main Zone audio output connector labeled Subwoofer L/R for a speaker setup that includes one, two, or no subwoofer(s). When a custom speaker setup is selected, the SUB L/R parameter opens the SUBWOOFERS L/R menu shown on page 3-26, which can be used to select the desired configuration for the Subwoofer L/R output connectors.
  • Page 70 SETUP Setting Crossover Points (continued from page 3-29) MAIN MENU MODE ADJUST AUDIO CONTROLS SETUP SETUP SYNTHESIS 7CH SETUP !CAUTION! !CAUTION! PRESSING THE V BUTTON WILL AUTOMATICALLY CHANGE THE OUTPUTS TO A SYNTHESIS 7CH SPEAKER CONFIGURATION Activates and deactivates the Main Zone audio output connector labeled LFE.
  • Page 71 SDP-40 ULTRA2 SUB SETUP SPEAKERS SET CROSSOVERS CUSTOM SETUP SETUP SPEAKERS SET CROSSOVERS Select ON if the subwoofer using the Main Zone audio output connectors labeled Subwoofer L/R is THX Ultra2-certified. When ON is selected, the BGC parameter can be used to adjust boundary gain compensation.
  • Page 72 SETUP CALIBRATING SPEAKER DISTANCES & OUTPUT LEVELS The SDP-40 offers manual calibration of speaker distances and output levels. Calibration helps to ensure accurate output signal arrival time and level at the primary listening position. However, it is not a substitute for proper speaker placement. Before calibrating speaker distances and output levels: •...
  • Page 73 SDP-40 Parameter Default Setting FRONT LEFT +0.0ft CENTER +0.0ft FRONT RIGHT +0.0ft SIDE LEFT +0.0ft REAR LEFT +0.0ft REAR RIGHT +0.0ft SIDE RIGHT +0.0ft MONO SUB* +0.0ft SUB RIGHT N/A† N/A† UNITS FEET * When one subwoofer is included in the speaker setup, this parameter is labeled MONO SUB. When two subwoofers are included in the speaker setup, this parameter is labeled SUB LEFT. †...

  • Page 74: Manual Calibration

    SDP-40 MANUAL CALIBRATION SETUP SPEAKERS MANUAL Selecting the SPEAKER SETUP menu MANUAL option opens the MANUAL SPEAKER SETUP menu shown below, which can be used to manually calibrate speaker distances and output levels. The table below indicates available manual calibration options. MAIN MENU MODE ADJUST AUDIO CONTROLS...
  • Page 75 SETUP Performing Manual Speaker Distance Calibration SETUP SPEAKERS MANUAL SPEAKER DISTANCES Selecting the MANUAL SPEAKER SETUP menu SPEAKER DISTANCES option opens the SPEAKER DISTANCES menu shown below, which can be used to manually calibrate speaker distances. MAIN MENU SETUP MODE ADJUST INPUTS SPEAKERS AUDIO CONTROLS...
  • Page 76 SDP-40 Performing Manual Output Level Calibration SETUP SPEAKERS MANUAL LEVELS CALIBRATION Selecting the MANUAL SPEAKER SETUP menu LEVELS CALIBRATION option opens the LEVELS CALIBRATION menu shown below, which can be used to manually calibrate output levels. MAIN MENU SETUP MODE ADJUST INPUTS SPEAKERS AUDIO CONTROLS...
  • Page 77 SETUP Performing Manual Output Level Calibration (continued from page 3-36) INTERNAL NOISE TEST SETUP SPEAKERS MANUAL LEVELS CALIBRATION Opens the INTERNAL NOISE message shown on the previous page, which indicates that the internal noise test generates loud calibration noise signals. When the INTERNAL NOISE message opens: •...
  • Page 78 The unit will temporarily disregard customized listening mode settings. DACS CALIBRATION For system optimization using DACS® and a JBL Synthesis Digital Equalizer, connect the left and right RCA outputs of the DACS® signal generator (EVP-1) to the #1 analog input (which is active in the TAPE input) and set the front panel volume level to 0dB.
  • Page 79 SETUP SETTING BASS PEAK LIMITERS SETUP SPEAKERS MANUAL LEVELS CALIBRATION Selecting the LEVELS CALIBRATION menu BASS PEAK LIMITERS option opens the BASS PEAK LIMITERS menu shown below, which can be used to set amplitude limits for low-frequency signals sent to the Main Zone audio output connectors labeled Subwoofer L/R and LFE as well as low-frequency signals redirected to other Main Zone audio output connectors.
  • Page 80 SDP-40 CAL NOISE SETUP SPEAKERS MANUAL LEVELS CALIBRATION CAL NOISE Determines whether bass peak limiters are set with an internal or external calibration source. When ON is selected, the SDP-40 activates an internal calibration noise signal to set bass peak limiters.

  • Page 81: Rear Panel Config

    SETUP REAR PANEL CONFIG SETUP REAR PANEL CONFIG Selecting the SETUP menu REAR PANEL CONFIG option opens the REAR PANEL CONFIG menu shown below, which can be used to configure the analog audio input connectors as eight stereo connectors or as five stereo and one 5.1-channel connectors. MAIN MENU SETUP MODE ADJUST...

  • Page 82: Display Setup

    SDP-40 DISPLAY SETUP SETUP DISPLAYS Selecting the SETUP menu DISPLAYS option opens the DISPLAY SETUP menu shown below, which can be used to customize the on-screen and front panel displays, restore audio/video synchronization, and create and activate a custom unit name. MAIN MENU MODE ADJUST AUDIO CONTROLS...

  • Page 83: Edit Custom Name

    SETUP Display Setup (continued from page 3-42) MAIN MENU MODE ADJUST AUDIO CONTROLS SETUP SETUP EDIT CUSTOM NAME SETUP DISPLAYS EDIT CUSTOM NAME Opens the EDIT CUSTOM NAME drop-down menu shown above, which can be used to create a custom unit name. The factory- default unit name is SDP-40.

  • Page 84: Edit Custom Name

    SDP-40 ON-SCREEN DISPLAY SETUP DISPLAYS ON-SCREEN DISPLAY Selecting the DISPLAY SETUP menu ON-SCREEN DISPLAY option opens the ON-SCREEN DISPLAY menu shown below, which can be used to customize the on-screen display. MAIN MENU SETUP MODE ADJUST INPUTS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG...

  • Page 85: Remote State

    SETUP On-Screen Display (continued from page 3-44) POSITION SETUP DISPLAYS ON-SCREEN DISPLAY POSITION Controls the vertical alignment of the two-line status on the display device screen. When TOP is selected, the two-line status appears near the top of the display device screen. When CENTER is selected, the two-line status appears centered on the display device screen.

  • Page 86: Edit Custom Name

    SDP-40 FRONT PANEL DISPLAY SETUP DISPLAYS FRONT PANEL DISPLAY Opens the FRONT PANEL DISPLAY menu shown below, which can be used to customize the front panel display. MAIN MENU SETUP MODE ADJUST INPUTS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS DISPLAYS VOLUME CONTROLS...

  • Page 87: Volume Control Setup

    SETUP VOLUME CONTROL SETUP SETUP VOLUME CONTROLS Selecting the SETUP menu VOLUME CONTROLS option opens the VOLUME CONTROL SETUP menu shown below, which can be used to configure Main Zone, Zone 2, and Record Zone volume levels. MAIN MENU SETUP MODE ADJUST INPUTS AUDIO CONTROLS...

  • Page 88: Trigger Setup

    SDP-40 REC PWR ON LAST LVL, -80 to +6dB SETUP VOLUME CONTROLS REC PWR ON Selects the volume level at which the Record Zone activates. When a value is selected, the SDP-40 automatically sets Record Zone volume level to the selected value when the Record Zone is activated.
  • Page 89 TRIGGER 2 SETUP REMOTE ONLY DVD1 DVD2 TRIGGER SETUP GAME TRIGGER 1 REMOTE TAPE TRIGGER 2 REMOTE TUNER ZONE2 INPUTS RECORD INPUTS FILM MUSIC MUSIC SURR PLII + PLII MOVIE PLII MUSIC PRO LOGIC FILM MUSIC NIGHTCLUB CONCERT HALL CHURCH CATHEDRAL PANORAMA PARTY...

  • Page 90: Lock Options

    SDP-40 MAIN MENU SETUP MODE ADJUST INPUTS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS LOCK OPTIONS When configured for program operation, the connector activates when the associated inputs or listening modes are activated and deactivates when the associated inputs or listening modes are deactivated.
  • Page 91 SETUP SETUP SETUP LOCK OPTIONS SETUP Protects SETUP menu branch settings from accidental changes. When LOCKED is selected, SETUP menu branch settings cannot be adjusted. When UNLOCKED is selected, SETUP menu branch settings can be adjusted. Note the following: • When the MODES parameter is set to LOCKED, the up and down arrows can still be used to adjust subwoofer output levels applied to the selected listening mode when the Shift...

  • Page 92: Audio Controls

    AUDIO CONTROLS AUDIO CONTROLS ........4-2 Bass •...
  • Page 93 AUDIO CONTROLS AUDIO CONTROLS Selecting the MAIN MENU AUDIO CONTROLS option opens the AUDIO CONTROLS menu shown below, which can be used to customize the Main Zone, Zone 2, and Record Zone audio output connectors. MAIN MENU AUDIO CONTROLS MODE ADJUST BASS +0.0dB AUDIO CONTROLS...
  • Page 94 SDP-40 BASS AUDIO CONTROLS BASS Controls the amount of low-frequency boost or cut applied to the Main Zone audio output connectors labeled Front L/R, Center, LFE, and Subwoofer L/R. The graph shown at the right indicates the frequency response of all BASS parameter settings. Note: When the Shift command bank is activated: •...
  • Page 95 AUDIO CONTROLS TREBLE AUDIO CONTROLS TREBLE Controls the amount of boost or cut applied to the Main Zone audio output connectors labeled Front L/R and Center. The graph shown at the right indicates the frequency response of all TREBLE parameter settings. Note: When the Shift command bank is activated: •...
  • Page 96 SDP-40 TILT EQ AUDIO CONTROLS TILT EQ Controls the amount of tilt equalization applied to the Main Zone audio output connectors labeled Front L/R, Center, LFE, and Subwoofer L/R. This parameter setting affects the entire frequency spectrum with a hinge point at 1kHz. As the setting increases, frequencies higher than 1kHz are boosted while frequencies lower than 1kHz are simultaneously cut.
  • Page 97 AUDIO CONTROLS LOUDNESS AUDIO CONTROLS LOUDNESS Controls the amount of low-frequency boost that is automatically applied to the Main Zone audio output connectors labeled Front L/R, Center, LFE, and Subwoofer L/R. When ON is selected, loudness compensation is automatically applied based on volume level. As volume level increases, the amount of low-frequency boost automatically decreases.
  • Page 98 SDP-40 BALANCE AUDIO CONTROLS BALANCE Controls the left-to-right balance of the Main Zone audio output connectors labeled Front L/R. Note: When the Shift command bank is activated: • Pressing the MENU button centers the Main Zone BALANCE parameter. • Pressing the arrow buttons adjusts the Main Zone BALANCE parameter left and right.

  • Page 99: Mode Adjust

    MODE ADJUST ........5-2 Listening Mode Activation .

  • Page 100: Listening Mode Activation

    MODE ADJUST MAIN MENU MODE ADJUST MODE ADJUST MODE ADJUST FILM AUDIO CONTROLS SETUP MUSIC MUSIC SURR PLII + PLII MOVIE PLII MUSIC PRO LOGIC FILM MUSIC NIGHTCLUB CONCERT HALL CHURCH CATHEDRAL PANORAMA PARTY 2-CHANNEL MONO LOGIC MONO SURROUND MONO FILM MUSIC MUSIC...

  • Page 101: Preferred Listening Mode Selection Parameters

    SDP-40 PREFERRED LISTENING MODE SELECTION PARAMETERS The SDP-40 allows the selection of four preferred listening modes for each Main Zone input, including one listening mode each for 2-channel, Dolby Digital, dts(-ES), and 5.1-channel analog sources. The table below indicates the INPUT SETUP menu parameters that can be used to select preferred listening modes.
  • Page 102 MODE ADJUST MODE BUTTONS The front panel and remote control Mode buttons can be used to audition listening modes with the current Main Zone input source. Pressing the Mode or + button scrolls upward through listening modes available for the current Main Zone input source. Pressing the Mode or –...

  • Page 103: Listening Mode Descriptions

    SDP-40 LISTENING MODE DESCRIPTIONS The SDP-40 offers an assortment of listening modes for 2-channel, Dolby Digital, dts(-ES), and analog sources. Listening mode descriptions begin below and continue in the order shown on the MODE ADJUST menu. The table included with each description indicates the corresponding listening mode menu parameters, as well as their factory-default and possible parameter settings.
  • Page 104 MODE ADJUST MODE ADJUST • A proprietary listening mode. • Similar to the FILM listening mode, but specifically tailored for broadcast sources. • Designed for enhanced playback of 2-channel stereo or matrix- encoded broadcast sources. • Recommended for 2-channel stereo or matrix-encoded broadcast sources.
  • Page 105 • A proprietary listening mode. • Similar to the MUSIC SURROUND listening mode available in other JBL products. • Designed for enhanced playback of 2-channel stereo music sources recorded in real spaces and for playback of recordings that contain added reverb.
  • Page 106 MODE ADJUST PLII MOVIE MODE ADJUST @*PLII MOVIE • Similar to the PRO LOGIC listening mode, but uses full- frequency stereo surround channels to realistically increase the perceived width of the listening space. • Designed for playback of Dolby Surround-encoded sources. •...

  • Page 107: Pro Logic

    SDP-40 PRO LOGIC MODE ADJUST @*PRO LOGIC • Designed for playback of Dolby Surround-encoded sources. • Decodes four channels from Dolby Surround-encoded sources. • Uses a mono surround channel with a high-frequency rolloff above 7kHz. • Available for comparison purposes, particularly with the FILM, PLII MOVIE, and FILM listening modes.

  • Page 108: Concert Hall

    MODE ADJUST NIGHTCLUB MODE ADJUST NIGHTCLUB • Designed for playback of “dry” music sources that benefit from the addition of room reflections, especially music sources that lack ambience in the recording. • Generates early reflections to simulate small, intimate listening spaces.
  • Page 109 SDP-40 CHURCH MODE ADJUST CHURCH • Uses a reverb algorithm to emphasize the rich, smooth, reverberant decay characteristic of small and medium listening spaces with long reverberation time relative to their size, such as churches and chambers. • Unlike other room simulation listening modes, this mode uses a proprietary reverb algorithm that is majority of recording engineers to add ambience to record- ings.
  • Page 110 MODE ADJUST PANORAMA MODE ADJUST PANORAMA • Designed for playback of stereo and matrix-encoded sources. • Uses proprietary algorithms to move the stereo image outward from the front speakers, producing a wider stereo field with greater depth. • Depends on proper location of the primary listening position and front speakers.
  • Page 111 SDP-40 Front Left Front Right L127 ..Center ..R127 To calibrate the PANORAMA listening mode: 1. Remove all obstructions between the primary listening position and the speakers. 2. Make sure the distances between the primary listening position and the speakers are properly measured.

  • Page 112: Mono Logic

    MODE ADJUST PARTY MODE ADJUST PARTY • Designed for playback of stereo sources. • Sends stereo sources to all channels. • Recommended for background music. Parameter OUTPUT LEVELS Refer to page 5-32 CUSTOM Refer to page 5-33 Listening mode menu parameter descriptions begin on page 5-34. 2-CHANNEL MODE ADJUST 2-CHANNEL...

  • Page 113: Mono Surround

    SDP-40 MONO SURROUND MODE ADJUST MONO SURROUND • Designed for playback of mono sources. • Sends mono sources to all channels. Parameter OUTPUT LEVELS Refer to page 5-32 CUSTOM Refer to page 5-33 Listening mode menu parameter descriptions begin on page 5-34. MONO MODE ADJUST MONO...
  • Page 114 MODE ADJUST MODE ADJUST • A proprietary listening mode. • Similar to the 5.1 FILM listening mode, but specifically tailored for broadcast sources. • Designed for enhanced playback of 5.1-channel Dolby Digital broadcast sources. • Recommended for 5.1-channel Dolby Digital broadcast sources.
  • Page 115 SDP-40 ULTRA2, 5.1 SurEX, & 5.1 MODE ADJUST ULTRA2 SurEX Listening mode name differs depending on the encoding present in the input source, the SURROUND EX parameter setting, and the speaker setup. The table below indicates the conditions in which THX Ultra2 and THX Surround EX decoding are engaged.
  • Page 116 MODE ADJUST ULTRA2, 5.1 SurEX, & 5.1 (continued from page 5-17) MODE ADJUST ULTRA2 SurEX • Designed for playback of 5.1-channel Dolby Digital film sources. • Allows 7-channel playback of 5.1-channel Dolby Digital sources without THX Surround EX encoding. • Applies THX re-equalization to simulate high-frequency rolloffs that occur in movie theaters.
  • Page 117 SDP-40 MUSIC MODE ADJUST MUSIC • Designed for playback of 5.1-channel Dolby Digital music sources. • The 5.1 MUSIC listening mode is not available unless both side and rear speakers are present. • Applies ASA processing to signals sent to the rear speakers. Refer to the ASA parameter description on page 3-31 for more information.
  • Page 118 MODE ADJUST DIGITAL EX & DIGITAL (continued from page 5-19) MODE ADJUST @*DIGITAL EX @*DIGITAL Note: The SDP-40 cannot automatically detect Dolby Digital Surround EX encoding in non-flagged 5.1- channel Dolby Digital sources. A non-flagged input source does not include information in the input signal identifies Dolby Digital Surround EX encoding.
  • Page 119 SDP-40 5.1 2-CHANNEL MODE ADJUST 5.1 2-CHANNEL • Designed for converting 5.1-channel Dolby Digital input signals into 2-channel LOGIC7-encoded output signals. • Sends downmixed 5.1-channel Dolby Digital input signals to the front speakers and the subwoofer. • Recommended for recording purposes. Default Parameter Setting...
  • Page 120 MODE ADJUST 5.1 MONO SURR MODE ADJUST 5.1 MONO SURR • Designed for playback of Dolby Digital mono sources. • Sends mono sources to all channels. Parameter OUTPUT LEVELS Refer to page 5-32 CUSTOM Refer to page 5-33 Listening mode menu parameter descriptions begin on page 5-34. 5.1 MONO MODE ADJUST 5.1 MONO...
  • Page 121 SDP-40 Input Source Parameter Setting DECODING: AUTO DECODING: ON DECODING: OFF FILM & FILM MODE ADJUST @@@! L7 FILM @@ L7 FILM • Listening mode name differs depending on the encoding present in the input source, the setting, and the speaker setup. Refer to the previous page for more information.
  • Page 122 MODE ADJUST MUSIC & MUSIC @@ L7 MUSIC MODE ADJUST @@@! L7 MUSIC • Listening mode name differs depending on the encoding present in the input source, the setting, and the speaker setup. Refer to page 5-22 for more information. •...
  • Page 123 SDP-40 • Applies THX timbre matching to minimize timbre differences between the front and surround channels, which results in smoother sound movements between them. • Recommended for home theaters with THX-certified speakers. When THX Ultra2 decoding is engaged: • Applies adaptive de-correlation to increase the perceived width of the listening space.
  • Page 124 MODE ADJUST MUSIC MODE ADJUST @@ @** MUSIC • Designed for playback of 5.1-channel dts music sources. • MUSIC listening mode is not available unless both side and rear speakers are present. • Applies ASA processing to signals sent to the rear speakers. Refer to the ASA parameter description on page 3-31 for more information.
  • Page 125 SDP-40 & 2-CHAN MODE ADJUST @@@* 2-CHAN • Designed for converting 5.1- or 6.1-channel dts(-ES) input signals into 2-channel LOGIC7-encoded output signals. • Sends downmixed 5.1- or 6.1-channel dts(-ES) input signals to the front speakers and the subwoofer. • Recommended for recording purposes. Default Parameter Setting...
  • Page 126 MODE ADJUST 5.1a MUSIC MODE ADJUST 5.1a MUSIC • A proprietary listening mode. • Similar to the 5.1a FILM listening mode, but specifically tailored for music sources. • Designed for enhanced playback of 5.1-channel analog music sources. • Recommended for 5.1-channel analog music sources. Default Parameter Setting...
  • Page 127 SDP-40 Input Source Parameter Setting SURROUND EX: ON 5.1a SURROUND EX: OFF 5.1a • Designed for playback of 5.1-channel analog film sources. • Allows 7-channel playback of 5.1-channel analog sources without THX Surround EX encoding. • Applies THX re-equalization to simulate high-frequency rolloffs that occur in movie theaters.
  • Page 128 MODE ADJUST 5.1a MUSIC MODE ADJUST 5.1a MUSIC • Designed for playback of 5.1-channel analog music sources. • The 5.1a MUSIC listening mode is not available unless both side and rear speakers are present. • Applies ASA processing to signals sent to the rear speakers. Refer to the ASA parameter description on page 3-31 for more information.
  • Page 129 SDP-40 5.1a 2-CHANNEL MODE ADJUST 5.1a 2-CHANNEL • Designed for converting 5.1-channel analog input signals into 2-channel LOGIC7-encoded output signals. • Sends downmixed 5.1-channel analog input signals to the front speakers and the subwoofer. • Recommended for recording purposes, particularly for recording from a DVD-A or multi-channel SACD player to a CD-R or another 2-channel recording format.
  • Page 130 MODE ADJUST 2CH BYPASS MODE ADJUST 2CH BYPASS • Designed for playback of 2-channel analog sources. • Sends analog audio input signals to the Main Zone audio output connectors labeled Front L/R. These signals receive no internal processing. • The 2CH BYPASS listening mode is automatically activated whenever a 2-channel analog source is present and the MAIN ADV menu ANALOG BYPASS parameter is set to ON.

  • Page 131: Reset Mode

    SDP-40 CUSTOM MODE ADJUST Listening Mode CUSTOM Opens the CUSTOM menu shown below, which can be used to compare custom and factory-default versions of the selected listening mode and to restore the factory-default version of the selected listening mode. CUSTOM VS PRESET MODE ADJUST Listening Mode CUSTOM...
  • Page 132 MODE ADJUST RESET MODE (continued from page 5-33) MODE ADJUST Listening Mode CUSTOM RESET MODE 2. When RESET MODE message appears, press the arrow button to close the message without restoring the factory-default version of the selected listening mode. Note: When the CUSTOM menu RESET MODE option is selected to restore the factory-default version of the selected listening mode, the corresponding TRIGGER SETUP menu listening mode parameter is automatically set to OFF.
  • Page 133 SDP-40 BASS ENHANCE Selecting the ON setting enhances stereo bass, which results in low-frequency reproduction that is less localizable and more realistic in the listening space. The effectiveness of the BASS ENHANCE parameter varies depending on room acoustics and the ability of the surround speakers to reproduce low frequencies.
  • Page 134 MODE ADJUST Listening Mode Menu Parameter Descriptions (continued from page 5-35) CTR WIDTH Adjusts the center image. When MIN is selected, the center image is heard from just the center speaker. When MAX is selected, the center image is heard from just the front left and right speakers as a “phantom”...

  • Page 135: Input Balance

    SDP-40 • STATUS menu includes an SB level meter when the DECODING parameter is set to ON and a 5.1-channel dts source is present or when the DECODING parameter is set to AUTO and a 5.1-channel matrix-encoded or 6.1-channel discrete-encoded dts-ES source is present. EX DECODING Controls the Dolby Digital Surround EX decoding feature, which can be used to extract a rear channel from 5.1-channel Dolby...

  • Page 136: Master Level

    MODE ADJUST Listening Mode Menu Parameter Descriptions (continued from page 5-37) Controls the output level of the Main Zone audio output connector labeled LFE. The OUTPUT LEVELS menu does not include the LFE parameter unless an LFE subwoofer is present. LFE MIX Controls the output level of LFE information –...
  • Page 137 SDP-40 OUTPUT LEVELS Opens the OUTPUT LEVELS menu, which can be used to adjust output levels for the Main Zone audio output connectors labeled Center, Subwoofer L/R, LFE, Side L/R, and Rear L/R. Refer to page 5-32 for more information. PANORAMA Selecting the ON setting extends the front stereo image to include surround channel signals, which creates a “wraparound”...
  • Page 138 MODE ADJUST Listening Mode Menu Parameter Descriptions (continued from page 5-39) SIZE Adjusts listening space length within a 4 to 20 or 30m range (depending on the listening mode). Increase the size of the space to increase the reverb effect. The full parameter range might not be available depending on the BASS RT and MID RT parameter settings.
  • Page 139 SDP-40 SURR ROLLOFF Applies high-frequency attenuation control to the Main Zone audio output connectors labeled Side L/R and Rear L/R. This filter is only applied to output signals generated by the SDP-40. SURROUND DLY Increases the perceived depth of the listening space by delaying the arrival time of signals from the side and rear speakers.
  • Page 140 MODE ADJUST Listening Mode Menu Parameter Descriptions (continued from page 5-41) SURROUND MIX Controls the relative level of surround channel information sent to the Main Zone audio output connectors labeled Front L/R. It is recommended to set this parameter to +2 or +3dB for all input sources.
  • Page 141 Troubleshooting & Maintenance Troubleshooting ........6-2 Routine Maintenance .

  • Page 142: Troubleshooting

    Troubleshooting & Maintenance TROUBLESHOOTING The SDP-40 does not power on. 1. Make sure the rear panel power switch is set to the|(“on”) position. 2. Attempt to deactivate standby mode with both the front panel and remote control standby buttons. 3. Examine the power cord to ensure a solid connection between the AC input connector and the wall outlet.
  • Page 143 A-19. Then, follow the instructions on the next page to restore factory-default settings. 3. Contact an authorized JBL dealer. 4. Contact JBL customer service at 818-830-8757. Note: Visit http://www.jblsynthesis.com/ for additional...

  • Page 144: Restoring Factory-Default Settings

    Troubleshooting & Maintenance ROUTINE MAINTENANCE The following routine maintenance should be performed on a periodic basis: • Clean the SDP-40 exterior surface with a soft, lint-free cloth. Do not use alcohol, benzene, acetone-based cleaners, or strong commercial cleaners. Do not use a cloth made with steel wool or metal polish.
  • Page 145 SDP-40 Note: The Mute button must be pressed within 2 seconds of deactivating standby mode. Otherwise, the "MUTE ON" message will appear on the on-screen and front panel displays. If this occurs, too much time has passed. Begin again with step 2. 5.
  • Page 146 Appendix Specifications ........A-2 Declaration of Conformity .

  • Page 147: Specifications

    Appendix SPECIFICATIONS Audio Input & Output Connectors Analog Audio Inputs • 8 stereo (RCA) or 5 stereo and one 5.1-channel connectors Digital Audio Inputs • 6 S/PDIF coaxial (RCA), 6 S/PDIF optical (5 TosLink and 1 optical mini jack), and 1 AES/EBU (XLR) connectors •...
  • Page 148 SDP-40 Zone 2 & Record Zone Audio Performance Signal-to-Noise Ratio • 105dB minimum, 108dB typical, 22kHz bandwidth Input Sensitivity • 200mVrms (4Vrms for maximum output level) Input Impedance • 100kΩ in parallel with 150pF Output Level • 200mVrms typical, 4Vrms maximum (RCA connectors) •...

  • Page 149: Declaration Of Conformity

    Bedford, MA 01730-1413 USA The equipment identified here conforms to the Directive(s) and Standard(s) specified above. Type of Equipment: Digital Controller Model: JBL SDP-40 Date: June 2003 Lexicon, Inc. Vice President of Engineering 3 Oak Park Bedford, MA 01730-1413 USA...

  • Page 150: Menu Trees

    SDP-40 MENU TREES MAIN MENU SETUP MODE ADJUST INPUTS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS INPUT SETUP REAR PANEL CONFIG DVD1 8 STEREO INPUTS DVD2 5 STEREO & 5.1 ANLG 8 STEREO INPUTS FOR REAR PANEL CFG 5 STEREO &...
  • Page 151 TRIGGER 2 REMOTE ONLY DVD1 DVD2 Appendix Menu Trees (continued from page A-5) GAME MAIN MENU SETUP TAPE TUNER MODE ADJUST INPUTS INPUTS AUDIO CONTROLS SPEAKERS ZONE2 INPUTS SETUP SETUP REAR PANEL CONFIG RECORD INPUTS DISPLAYS VOLUME CONTROLS FILM TRIGGERS LOCK OPTIONS MUSIC MUSIC SURR...
  • Page 152 SDP-40 MAIN MENU SETUP MODE ADJUST INPUTS INPUTS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS DVD1 INPUT NAME DVD1 ANALOG IN EDIT INPUT NAME ANALOG-1 RESTORE DEFAULT NAME ANALOG-2 ANALOG-3 ANALOG-4 PRESS MENU V TO ANALOG-5 RESTORE INPUT NAME ANALOG-6...
  • Page 153 Appendix Menu Trees (continued from page A-7) MAIN MENU SETUP MODE ADJUST INPUTS INPUTS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS DVD1 MAIN ADV SAT MAIN ADV INPUT SELECT DIGITAL INPUT SELECT AUTO ANALOG BYPASS ANALOG BYPASS S-VIDEO 16:9...
  • Page 154 SDP-40 MAIN MENU SETUP MODE ADJUST INPUTS SPEAKERS AUDIO CONTROLS SPEAKERS SETUP SETUP REAR PANEL CONFIG DISPLAYS VOLUME CONTROLS TRIGGERS LOCK OPTIONS CUSTOM SETUP FRONT L/R 40Hz CENTER 60Hz SIDE L/R 60Hz REAR L/R 60Hz SUB L/R MONO SUB XOVER 40Hz ULTRA2 SUB APART...
  • Page 155 Appendix Appendix MAIN MENU MODE ADJUST AUDIO CONTROLS SETUP SETUP SPEAKER DISTANCES FRONT LEFT 0.0ft CENTER 0.0ft FRONT RIGHT 0.0ft SIDE RIGHT 0.0ft REAR RIGHT 0.0ft REAR LEFT 0.0ft SIDE LEFT 0.0ft MONO SUB 0.0ft SUB RIGHT UNITS FEET METERS 0.0 to 30.0ft or 12.0m FEET MAIN MENU...
  • Page 156 SDP-40 Menu Trees (continued from page A-10) MAIN MENU MODE ADJUST MODE ADJUST MODE ADJUST FILM AUDIO CONTROLS SETUP MUSIC MUSIC SURR PLII + PLII MOVIE PLII MUSIC PRO LOGIC FILM MUSIC NIGHTCLUB CONCERT HALL CHURCH CATHEDRAL PANORAMA PARTY 2-CHANNEL MONO LOGIC MONO SURROUND MONO...
  • Page 157 Appendix Appendix PARTY OUTPUT LEVELS VOCAL ENHANCE +0.0dB CUSTOM 5 SPKR ENHANCE BASS ENHANCE RE-EQUALIZER 2-CHANNEL REAR DLY OFFSET SUB L/R LVL +0dB COMPRESSION CUSTOM LFE MIX OUTPUT LEVELS CUSTOM MONO LOGIC EFFECT LVL -9dB MUSIC ACADEMY FILTER SURR ROLLOFF 3.1kHz VOCAL ENHANCE +0.0dB OUTPUT LEVELS...
  • Page 158 SDP-40 Menu Trees (continued from page A-12) Selecting the listening mode menu CALIBRATION, OUTPUT LEVELS, or CUSTOM option opens the corresponding menu shown below. The CALIBRATION option is available for the PANORAMA listening mode. The OUTPUT LEVELS and CUSTOM options are available for most listening modes. These menus are identical regardless of which listening mode is selected.
  • Page 159 Appendix Appendix INPUT BALANCE MASTER LEVEL L< <|> >R -5 to +5dB LFE MIX MID RT -20.0 or -10.0 to +0.0dB 24ms to 24.3s LISTENER POSITION PANORAMA -127 +127 LIVENESS PRE-DELAY 30ms to 20.2s OFF, 1 to 100ms LOW FREQ WIDTH RE-EQUALIZER -25 to +25dB A-14...
  • Page 160 SDP-40 Menu Trees (continued from page A-14) FACTORY SETTINGS FACTORY SETTINGS EXIT HAVE BEEN RESTORED RESTORE DEFAULTS RESTORE DEFAULTS PRESS ANY KEY TO RESTART When the Shift command bank is activated, pressing the STAT button opens the status menu for the current input source. Status menus are available for 2-channel, Dolby Digital, dts(-ES), analog, and digital input sources.

  • Page 161: Installation Worksheet

    Appendix INSTALLATION WORKSHEET INPUT SETUP DVD1 DVD2 NAME DIGITAL IN ANALOG IN ANLG IN LVL VIDEO IN COMPONENT IN 2-CH 5.1a MAIN ADVANCED INPUT SELECT ANALOG BYPASS S-VIDEO 16:9 S-VIDEO OSD 4:3 COMPONENT OSD ZONE2 IN RECORD IN RECORD ADVANCED ANLG IN LVL DIGITAL BYPASS DIG OUT RATE...
  • Page 162 SDP-40 Installation Worksheet (continued from page A-16) SPEAKER SETUP CUSTOM SETUP FRONT L/R CENTER SIDE L/R REAR L/R SUB L/R 1 2 3 SUB XOVER ULTRA2 SUB UNITS BASS PEAK LIMITERS CAL NOISE L/R LIMITER L/R LIMIT ADJ LFE LIMITER LFE LIMIT ADJ REAR PANEL CONFIG Circle one.
  • Page 163 Appendix DISPLAY SETUP ON-SCREEN DISPLAY STATUS POSITION FORMAT BACKGROUND REMOTE STATE FRONT PANEL DISPLAY STATUS BRIGHTNESS A/V SYNC DELAY CUSTOM NAME EDIT CUSTOM NAME AUDIO CONTROLS BASS TREBLE TILT EQ LOUDNESS BALANCE FADER ZONE2 BALANCE RECORD BALANCE A-18 TRIGGER 1 SETUP Circle all parameters set to ON.
  • Page 164 SYMBOLS & LOGOS Documentation Conventions, ii , see Dolby , see also dts, dts-ES, dts(-ES) , see dts Neo:6 , see ES , see LOGIC7 , see THX NUMBERS 2.0 ENCODING Parameter, 2-21, 2-23 2-CH Parameter, 3-11, 3-12 to 3-13 (menu ill.), 5-3, A-7 (menu ill.), A-19 2-CH SURROUND Listening Mode, 5-14, A-15 (menu ill.)
  • Page 165 Index (continued) AUTO Parameter, 3-8 to 3-9, A-7 BACKGROUND Parameter, 3-44, 3-45, A-5 BALANCE Parameter, 4-2, 4-7, A-10 BASS CONTENT Parameter, 5-12, 5-34, A-13 BASS ENHANCE Parameter, 5-5, 5-6, 5-7, 5-15, 5-16, 5-23, 5-24, 5-27, 5-28, 5-35, A-13 BASS Parameter, 4-2, 4-3 (frequency-response graph), A-10 BASS PEAK LIMITERS Menu, 3-39 (ill.), A-10 (ill.), A-20 BASS RT Parameter, 5-11, 5-35, A-13...
  • Page 166 EDIT CUSTOM NAME Option, 3-42, 3-43, A-5 EDIT INPUT NAME Option, 3-4 to 3-5 (menu ill.), A-7 EFFECT LVL Parameter, 5-10, 5-11, 5-12, 5-14, 5-21, 5-36, A-13 DECODING Parameter, 5-23, 5-24, 5-25, 5-26, 5-27, 5-36 to 5-37, A-13 ENCODING Parameter, 2-21, 2-23 EX DECODING Parameter, 5-20, 5-37, A-13 EX ENCODED Parameter, 2-21, 2-23 External Noise Test, 3-34,...
  • Page 167 Index (continued) FILM Listening Mode, 5-4, 5-5, A-11 (menu ill.) MUSIC Listening Mode, 5-4, 5-6, A-11 (menu ill.) MUSIC SURR Listening Mode, 5-7, A-11 (menu ill.) TV Listening Mode, 5-4, 5-6, A-14 (menu ill.) LOUDNESS Parameter, 4-2, 4-6 (frequency-response graph), A-10 LOW FREQ WIDTH Parameter, 5-12, 5-38, A-11 Lowpass Filter, 3-23 (ill.) MAIN ADV Menus, 3-14 (ill.), A-7 (ill.), A-8 (ills.)
  • Page 168 (continued) PARAMETERS Preferred Listening Mode Selection, 5-3 Selecting, 2-11 to 2-12 POSITION Parameter, 3-44, 3-45, A-5 Power Switch, 2-5 PRE-DELAY Parameter, 5-10, 5-11, 5-39, A-14 Preferred Listening Mode Selection Parameters 2-CH Parameter, 3-11, 3-12 to 3-13 (menu ill.), 5-3, A-7 (menu ill.) D Parameter, 3-11, 3-12 (menu ill.), 3-13, 5-3, A-7 (menu ill.), A-11 Parameter, 3-11, 3-12 (menu ill.), 3-13,...
  • Page 169 Index (continued) SPEAKER SETUP Menu, 3-2, 3-21 to 3-40 (ills.), A-5 (ill.), A-9 to A-10 (ills.) SPEAKER SETUP PARAMETERS ASA, 3-25, 3-31 to 3-32, A-9, BGC, 3-25, 3-31, A-9 CENTER, 3-25, 3-26 (menu ill.), 3-27, A-9 (menu ill.), A-20 FRONT L/R, 3-25, 3-26 to 3-27 (menu ill.), A-9 (menu ill.) LFE, 3-25, 3-30, A-9, A-10 REAR L/R, 3-25, 3-26 (menu ill.), 3-28 (menu ill.),...
  • Page 170 830-8757 for further assistance. Who pays for what? JBL will be happy to pay all labor and material expenses for all repairs covered by this warranty. If necessary repairs are not covered by this warranty or if a unit is examined which is not in need of repair, you will be charged for the repairs or the examination.
  • Page 171 JBL SIS Products Group 8500 Balboa Boulevard Northridge, CA 91329 250 Crossways Park Drive Woodbury, NY 11797 800-336-4JBL Part No. 070-14991 | Rev 2 | 06/03...

Table of Contents
