Data Output Format (Line Format)
You can output the value displayed in the measured value line
and the weight unit, with or without a data ID code. Whether
the data ID code is included in the output depends on your
settings under "Line Format".
Examples:
+
235 pcs
Qnt
+
235 pcs
Line Format settings:
For raw data (16 characters): no "data header"
For other apps. 22 characters): with "data header"
(factory setting).
Output format with 16 characters
Display segments that are not activated are output as spaces.
Characters without a decimal point are output without
a decimal point.
The type of character that can be output depends on the
character's position:
Normal Operation
Pos. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+ * D D D D D D D D * U U U CR LF
or
- * D D D D D D D D * U U U CR LF
or
* * * * * * * * * * * * * * CR LF
+-:
Plus or minus sign
*:
Space
D:
Digit or letter (max. 7 characters plus decimal point)
U:
Character for unit of measurement
(1 to 3 letters followed by 0 to 2 spaces)
CR:
Carriage return
LF:
Line feed
Special Codes
Pos. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
* * * * * * – – * * * * * * CR LF
or
* * * * * * H * * * * * * * CR LF
or
* * * * * * H H * * * * * * CR LF
or
* * * * * * L * * * * * * * CR LF
or
* * * * * * L L * * * * * * CR LF
or
* * * * * * C * * * * * * * CR LF
*:
Space
– –: Final readout mode
H:
Overload
HH: Overload in Checkweighing
L:
Underload
LL:
Underload in Checkweighing
C:
Calibration/adjustment
1
)
depends on scale type; for example, not all units are
available on scales verified for use in legal metrology.
Without data ID code
With data ID code
1
)
Error Codes
Pos. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
* * * E r r * * # # * * * * CR LF
or
* * * E r r * # # # * * * * CR LF
*:
Space
#:
Error code number (2 or 3 digits)
Example: Output of the weight value +1255.7 g
Pos. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+ * * * 1 2 5 5 .
Position 1:
Plus or minus sign or space
Position 2:
Space
Positions 3-10:
Weight value with decimal point;
leading zeros are output as spaces.
Position 11:
Space
Positions 12-14: Unit symbol or space
Position 15:
Carriage return
Position 16:
Line feed
Data Output Format with 22 Characters
When data is output with an ID code, the 6-character code
precedes the 16-character string described above. The code
identifies the subsequent value.
Normal Operation
Pos. 1 2 3 4 5 6 7 8 9 10 11 1213 14 15 16 17 18 19 20 21 22
I I I I I I + * D D D D D D D D * U U U CRLF
or
I I I I I I - * D D D D D D D D * U U U CRLF
or
* * * * * * * * * * * * * * * * * * * * CRLF
I:
ID code character
, right-justified with spaces
1
+-:
Plus or minus sign
*:
Space
D:
Digit or letter (max. 7 characters plus decimal point)
U:
Character for unit of measurement
(1 to 3 letters followed by 0 to 2 spaces)
CR:
Carriage return
LF:
Line feed
Special Codes
Pos. 1 2 3 4 5 6 7 8 9 10 11 1213 14 15 16 17 18 19 20 21 22
S t a t * * * * * * * * – – * * * * * * CRLF
or
S t a t * * * * * * * * H * * * * * * * CRLF
or
S t a t * * * * * * * * H H * * * * * * CRLF
or
S t a t * * * * * * * * L * * * * * * * CRLF
or
S t a t * * * * * * * * L L * * * * * * CRLF
or
S t a t * * * * * * * * C * * * * * * * CRLF
*:
Space
H:
Overload
L:
Underload
C:
Calibration/adjustment
7 * g * * CR LF
1
)
– –: Final readout mode
HH: Overload in Checkweighing
LL: Underload in Checkweighing
55
