Sartorius Cubis MCE Series Operating Instructions Manual
High-capacity micro balance
Hide thumbs
Also See for Cubis MCE Series:
- Operating instructions manual (77 pages) ,
- Operating instructions manual (86 pages) ,
- Operating instructions manual (71 pages)
Subscribe to Our Youtube Channel
Related Manuals for Sartorius Cubis MCE Series
Summary of Contents for Sartorius Cubis MCE Series
- Page 1 Operating Instructions Original Operating Instructions Cubis ® MCE Models High-capacity Micro Balance 1000112172...
-
Page 3: Table Of Contents
Contents Contents 1 About These Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Validity . - Page 4 Contents Parameter List ..............30 4.8.1 Parameters in the “SETUP/BALANCE”...
- Page 5 Contents 8 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 Observing Warm-up Time .
- Page 6 17 Sartorius Service . . . . . . . . . . . . . . . . . . .
-
Page 7: About These Instructions
About These Instructions About These Instructions Validity These instructions are part of the device; they must be read in full and stored. These instructions apply to the device in the following versions: Device Model Cubis high-capacity micro balance MCE36S-3 | MCE36P-3 | ®... -
Page 8: Symbols Used
About These Instructions Symbols Used 1.4.1 Warnings in Operation Descriptions WARNING Denotes a hazard that may result in death or serious injury if it is not avoided. CAUTION Denotes a hazard that may result in moderate or minor injury if it is not avoided. -
Page 9: Safety Instructions
Modifications to the Device If the device is modified: Persons may be put at risk. Device-specific documents and product approvals may lose their validity. For queries regarding modifications to the device, contact Sartorius. Operating Instructions Cubis | MCE Models ®... -
Page 10: Repairs And Maintenance On The Device
Sartorius recommends that any repair work, even that carried out after the end of the warranty period, is carried out by Sartorius Service or after consulting with Sartorius Service. Only the maintenance tasks described in these instructions should be carried out. -
Page 11: Electrical Equipment
Only use the original power supply unit and power supply cable provided with the device. If the power supply unit or power supply cable needs to be replaced: Contact Sartorius Service. Do not repair or modify the power supply unit or power supply cable. 2.5.2... -
Page 12: Risk Of Injury During Transporting
Do not allow items to fall onto the operating display. In the event of damage to the operating display or draft shield, do not use the device. Contact Sartorius Service. 2.10 Trip Hazard From Connection Cable! If the device’s connection cables, e.g. the power supply cable, are laid haphazardly: People may trip over the connection cables and injure themselves. -
Page 13: Device Description
Device Description Device Description Device Overview Fig. 1: Cubis high-capacity micro balance, with motorized draft shield and 50 mm weighing pan (example) ® Pos . Name Description Weighing chamber Draft shield Cooling element Weighing module Contained in the housing. Leveling foot Motorically adjustable. Located on the bottom of the device. Proximity sensor Enables contact-free opening of the doors of a motorized draft shield. -
Page 14: Draft Shield
Device Description Draft Shield The draft shield can be opened motorically or manually, depending on the version of the device. When opening the draft shield, the top and side doors slide backwards. The top and side doors can be opened together or independently. -
Page 15: Components In The Weighing Compartment
Device Description Components in the Weighing Compartment Fig. 3: Components in the weighing compartment and 50 mm weighing pan (example) Pos . Name Description Rear wall of weighing compartment Guide for glass insert Available as an accessory. Ionizer nozzle The ionizer function must be activated in the control display. Base plate of weighing compartment Can be taken out, e.g. -
Page 16: Connections
Device Description Connections 3.4.1 Back of the Device Fig. 4: Connections on the back of the device, seal for conformity-assessed devices removed Pos . Name Description Slot For attaching a “Kensington” anti-theft device. USB-C connection For connecting accessories. USB-A connection For connecting accessories. -
Page 17: Rear Wall Of Weighing Compartment
Fig. 6: Connections to the operating display, cover removed Pos . Name Description Weighing module connection Receives the connection cable for the operating display. USB-C connection Concealed, no function, for Sartorius Service only Operating Instructions Cubis | MCE Models ®... -
Page 18: Protective Caps And Covers For Connections
Device Description Protective Caps and Covers for Connections Fig. 7: Protective caps and covers on the rear wall of the weighing compartment, the back of the device, the underside of the device, and the operating display Pos . Name Description Cover for rear wall of weighing compartment Installed in the rear wall of the weighing compartment. -
Page 19: Conformity-Assessed Devices
Device Description Conformity-assessed Devices Some settings of conformity-assessed models are protected against operator changes, e.g. “external calibration”. This measure is intended to ensure the suitability of the devices for use in legal metrology. Accessories Accessories are available for the device. These enable the device to be customized to the specific conditions during weighing procedures, e.g. -
Page 20: Operating Design
Operating Design Operating Design Operating Display in Weighing Mode Fig. 8: Operating display in weighing mode (example) Pos . Name Description Symbols for the selected application Weight value display In the selected basic unit. Metrological data Weight units Shows the selected basic unit, e.g. grams, [g]. Visual touch-feedback Visual note on an active button or key. -
Page 21: Operating Display In The Menu
Operating Design Operating Display in the Menu Fig. 9: Operating display in the menu (example) Pos . Name Description Position in the 1st menu level Shows the position of the displayed menu or configuration value in up to 4 menu levels. Position in the 2nd menu level Position in the 3rd menu level Position in the 4th menu level... - Page 22 Operating Design Symbol Name Description [Ionizer] button — Starts an ionization process. — If the button is flashing: The ioniziation process is performed. [Leveling] button Starts a leveling process. [GLP] button — Exits the GLP printout and starts printing the GLP footer. —...
-
Page 23: Displays In The Operating Display
Operating Design Displays in the Operating Display Symbol Name Description [Leveling] display — Indicates that the device is leveled. — If the center circle is flashing: Indicates that the device is not leveled. [Leveling] display Flashes while the device is leveling. [Counting] display Indicates that the “Counting”... -
Page 24: Licensable Device Functions
Operating Design Symbol Name Description [Quantity] display Indicates that a quantity is being displayed. [Invalid weight value] display — Indicates that the display does not contain a weight value, but is instead the calculated result of an application, e.g., for the “Totalizing”... -
Page 25: Navigating The Menus
Operating Design Navigating the Menus Procedure To access the settings menu: Press the [Menu] button. To scroll through all menus in the same level: Press the [Up] or [Down] button. To switch to the displayed menu level: Press the [Confirm] button. To scroll through the configuration values: Press the [Up] or [Down] button. - Page 26 Operating Design If an integer reference value needs to be selected in the reference value display (1) of a selected application, e.g. “Weighing in percent” or “Animal weighing” applications: Press the [Up] or [Down] button. This increases or decreases the reference value by 1.
-
Page 27: Menu Structure
Operating Design Menu Structure 4.7.1 Menu Structure in the Main Menu Navigating the menus (see Chapter 4.6, page 25). Level 1 Level 2 Description SETUP BALANCE Set the functions of the device. GEN.SERV. Reset the menu to factory settings. “General services” DEVICE USB.RS232 Define the parameters for the COM interface or display a... - Page 28 Operating Design Level 1 Level 2 Description APPLIC. WEIGH — Determine the weight value of a sample. “Applications” (Factory setting) — Activate the functions for all applications. COUNT Determine the number of parts that have approximately equal weight. PERCENT Determine the percentage share of a “Percent weighing”...
-
Page 29: Menu Structure In The "Unit Change" Menu
Operating Design Level 1 Level 2 Description INFO VER. NO. Display the software version number. “Device “Version number” information” SER. NO. Display the device’s serial number. “Serial number” MODEL Display the device’s model designation. APC VER. Display the software version of the APC processor. BAC VER. -
Page 30: Parameter List
Operating Design Parameter List 4.8.1 Parameters in the “SETUP/BALANCE” Menu Parameter Settings Explanation AMBIENT STABLE* Sets the ambient conditions to “stable”. Recommended for the following work environment: — Stable table — Slight movement in the room — Slight draft UNSTABL. Sets the ambient conditions to “unstable”: Activates the delayed change in weight values with a reduced output rate. - Page 31 Operating Design Parameter Settings Explanation ST.DEL. SHORT* Sets the stability delay to “short”: The stability symbol only appears after a short delay in order to provide a reliable result despite fluctuations. MEDIUM Sets the stability delay to “medium”: The stability symbol only appears after a longer delay in order to provide a reliable result in case of higher fluctuations.
-
Page 32: Parameters In The "Setup/Gen.serv." Menu
Operating Design Parameter Settings Explanation ON Z/T Activates the initial taring | zeroing. The device is tared or zeroed after it is switched on. Deactivates the initial taring | zeroing: After it is switched on, the device shows the same value as before it was last switched off. ISOCAL Activates the isoCAL function. -
Page 33: Parameters In The "Device/Usb.rs232" Menu
Operating Design 4.8.3 Parameters in the “DEVICE/USB.RS232” Menu Parameter Settings Explanations DAT.REC. SBI.WEIGH. Enables a faster SBI communication, only for software commands to the weighing module. XBPI Extended range of commands to control numerous balance functions with binary protocol for direct communication with the weighing module. SBI* Enables SBI communication. -
Page 34: Parameters In The "Device/Pc-Usb" Menu
Operating Design 4.8.4 Parameters in the “DEVICE/PC-USB” Menu Parameter Settings Explanations DAT.REC. SBI.WEIGH. Enables a faster SBI communication, only for software commands to the weighing module. XBPI Extended range of commands to control numerous balance functions with binary protocol for direct communication with the weighing module. SBI* Enables SBI communication. -
Page 35: Parameters In The "Device/D.shield" Menu
Operating Design 4.8.6 Parameters in the “DEVICE/D.SHIELD” Menu Parameter Settings Explanation CONTROL Deactivates the [Change] key for the motorized draft shield. Activates the [Change] key for the motorized draft shield. IONIZER OFF* Deactivates the ionizer for the operation of the draft shield. Closing the draft shield activates the ionizer. -
Page 36: Parameters In The "Device/Leveling" Menu
Operating Design 4.8.8 Parameters in the “DEVICE/LEVELING” Menu Parameter Settings Explanation LEVEL The device does not display messages on the status of the level. NOTE* The [LEVELING] display flashes if the device needs to be leveled. ERR.MSG. The [LEVEL.ERR.] message appears in the operating display if the device has not been leveled. -
Page 37: Parameters In The "Device/Extras" Menu
Operating Design 4.8.10 Parameters in the “DEVICE/EXTRAS” Menu Parameter Settings Explanation MENU EDITABL.* Activates write access: The menu parameters can be changed. RD.ONLY Activates read access: The menu parameters cannot be changed. SIGNAL Switches the acoustic signal off. QUIET Sets the volume of the acoustic signal to “quiet”. MEDIUM* Sets the volume of the acoustic signal to “medium”. -
Page 38: Parameters In The "Data.outp./Com.sbi" Menu
Operating Design 4.8.11 Parameters in the “DATA.OUTP./COM.SBI” Menu Parameter Settings Explanations COM. OUTP. IND.NO* Starts the data output after pressing the key or software command as an individual value without stability. IND.AFTER Starts the data output after pressing the key or software command as an individual value after stability. -
Page 39: Parameters In The "Data.outp./Pc.direct." Menu
Operating Design Parameter Settings Explanation PRT.INIT. Deactivates the output of the application parameters. ALL* Print command prints all parameters. MAIN PAR. Print command only prints the main parameters. OFF* Deactivates the GLP print. CAL.-ADJ. Activates the GLP printout for all calibration and adjustment processes. ALWAYS The GLP print is always switched on. -
Page 40: Parameters In The "Applic./Weigh" Menu
Operating Design 4.8.14 Parameters in the “APPLIC./WEIGH” Menu Parameter Settings Explanation UNIT Deactivates the “Unit change” function. Activates the “Unit change” function. * Factory setting 4.8.15 Parameters in the “APPLIC./COUNT” Menu Parameter Settings Explanation RESOLUT. DISP.ACC.* Sets the resolution to “display resolution”. The “Counting” application is started with the displayed value. -
Page 41: Parameters In The "Applic./Total" Menu
Operating Design 4.8.18 Parameters in the “APPLIC./TOTAL” Menu Parameter Settings Explanation PRT.COMP. Deactivates the component printout. Activates the component printout. * Factory setting 4.8.19 Parameters in the “APPLIC./ANIMALW.” Menu Parameter Settings Explanation ACTIVIT. CALM Sets the intensity of the “Animal activity” to “calm”. Recommended for minor movements of the sample, e.g. -
Page 42: Parameters In The "Applic./Density" Menu
Operating Design 4.8.21 Parameters in the “APPLIC./DENSITY” Menu Parameter Settings Explanation DEC.PLCS NONE The result of the “Density determination” application is displayed without decimal places. 1 DEC.PL.* The result of the “Density determination” application is displayed to 1 decimal place. 2 DEC.PL. -
Page 43: Parameters In The "Language" Menu
Operating Design Parameter Settings Explanation SERV.PASS. Maximum of Activates service mode. 8 characters 09-0, A-Z, - , space CAL.WT. Changes the calibration weight for the adjustment or calibration process with the user-defined weight value. INTERV. 0–9,999 Changes the interval for the automatic data output of the parameters seconds “DATA.OUTP. -
Page 44: Installation
Installation Installation Scope of Delivery Article Quantity Device Base plate of weighing compartment High-capacity micro balance: 50 mm weighing pan, slotted Shield plate for 50 mm weighing pan Power supply unit Country-specific power supply cable with test seal USB connection cable Operating display for Cubis ® Connection cable for operating display, installed on delivery Draft shield Front panel... -
Page 45: Selecting An Installation Site
Grip the device by the grooves (1) on the left and right-hand side and lift the device out of the bottom layer of foam packaging. Place the device down on a stable, completely flat surface. Sartorius recommends keeping the original packaging to return the device appropriately, e.g., for repairs. Attaching or Removing the Operating... -
Page 46: Placing The Device On Its Side And Installing
Installation Placing the Device on its Side and Installing For some installation work, the device has to be placed on its side, for example when inserting connection cables. Material: 1 soft support base, for placing down the device Requirement — There are no components installed in the pan retainer. —... -
Page 47: Positioning The Weighing Pan And Associated Components
Installation Positioning the Weighing Pan and Associated Components Procedure Insert the base of the weighing compartment (3) into the device. If there is a weighing pan with a shield plate: Place the shield plate (2) onto the pan retainer in the base of the weighing compartment. Insert the weighing pan (1) into the pan retainer. If the weighing pan needs to be turned, e.g. with sample holders: Lift the weighing pan and turn it to the left or right. -
Page 48: Installing The Control Unit
Installation Insert the panel mount for the front panel into the recesses in the front of the device. Installing the Control Unit The control unit can be installed in front of or next to the device. Procedure Remove the operating display from the device. Place the control unit in the preferred position (for the dimensions for positioning the control unit, see Chapter “15.1 Dimensions and Weights”, page 77). -
Page 49: Getting Started
Procedure Check whether the country-specific power plug matches the power supplies at the installation site. If required: Contact Sartorius Service. Check whether the voltage specifications on the manufacturer’s ID label match those of the power supply at the installation site. -
Page 50: Connecting Accessories
Getting Started Connect the device to the power supply at the installation site. To do this, connect the power plug from the power supply cable into the power socket. The device is switched on and performs the initial functions for device startup. -
Page 51: System Settings
System Settings System Settings Switching the Device On or Off The function of the [On | Off] key can be set and behaves differently. The following describes the start-up and shut-down with the factory setting. Procedure To switch the device on: Press the [On | Off] key. To switch the device off: Press and hold the [On | Off] key. -
Page 52: Entering The License Key
For the licensing of device functions, the corresponding application must be stored on the device. The application may be available upon delivery of the device, or it may saved to the device at a later stage by Sartorius Service. Requirements The application is stored on the device and the license key is known. -
Page 53: Configuring Motorized Opening And Closing Of The Draft Shield
System Settings Configuring Motorized Opening and Closing of the Draft Shield Pressing the [Change] key on the operating display of the device enables the doors of the draft shield to be opened of closed motorically. The draft shield has a learning capability which enables the following opening parameters to be saved: —... -
Page 54: Operation
Operation Operation Observing Warm-up Time After connecting to the power supply, the warm-up time must be observed. This enables the device to reach its required operating temperature and ensures accurate values during weighing processes. If this relates to a conformity-assessed device: The weight value is marked as invalid during the warm-up period. -
Page 55: Opening Or Closing Via Proximity Sensors
Operation 8.3.2 Opening or Closing via Proximity Sensors The proximity sensor works in “crossover mode”: — Left proximity sensor: Opens and closes the right-hand and the upper door — Right proximity sensor: Opens and closes the left-hand and the upper door The sensitivity of the proximity sensors can be adjusted (see Chapter “4.8.6 Parameters in the “DEVICE/D.SHIELD”... -
Page 56: Calibration, Adjustment Or Linearization
Operation Calibration, Adjustment or Linearization Function Description Calibration The device checks how much the displayed value deviated from the specified setpoint. Adjustment The device corrects the deviation to the setpoint. Linearization The device corrects the deviation from the ideal characteristic curve and the setpoint. -
Page 57: Adjusting With The Isocal Function
Operation 8.5.1 Adjusting with the isoCAL Function The device can be automatically internally calibrated and adjusted using the isoCAL function. Requirements — The isoCAL function is set up (for the configuration values for the “ISOCAL” parameter, see Chapter “4.8.1 Parameters in the “SETUP/ BALANCE”... - Page 58 Operation The calibration and adjustment function is executed: — If automatic leveling is configured: The device levels itself automatically. — The [CAL.RUN.] display appears and the [Adjust] button flashes. — The internal adjustment weight is loaded. — The device is automatically calibrated and the internal calibration weight is removed.
-
Page 59: Externally Calibrating The Device
Operation 8.5.3 Externally Calibrating the Device (Not for Conformity- assessed Models) Selecting Weight Value Used for External Calibration and Adjustment A preset weight value or a user-defined weight value can be used. Procedure If the preset weight value needs to be used: In the “SETUP”... - Page 60 Operation The calibration and adjustment function is executed: — If the adjustment weight placed on the device is within the specified limits: The device is automatically adjusted after the calibration. — If the weight placed on the device is too high: The “+” symbol is displayed. — If the weight placed on the device is too low: The “-” symbol is displayed. — The [CAL.END.] message indicates the end of calibration. Remove the adjustment weight.
-
Page 61: Weighing
Operation Weighing When weighing chemicals, suitable vessels must be used for the material to be weighed. This makes it possible to prevent damage to the device or its accessories. Requirements The device is leveled and adjusted. Procedure Press the [Zero] key. If below-balance weighing is being carried out: Suspend the sample on the hook for below-balance weighing, e.g. -
Page 62: Weighing Results With Id Marking
Operation 8.7.2 Weighing Results with ID Marking The device and every lot can be assigned an ID number. The ID numbers are provided in the GLP header during GLP-compliant printing. Requirements — In the “DATA.OUTP. / INPUT / ID NO.” menu, an ID number is entered for the device. -
Page 63: Running Applications (Examples)
Operation Running Applications (Examples) 8.9.1 Executing the “Unit Change” Function The “Unit change” function enables a switch between the basic unit display and up to 4 other units. The units can be set during the weighing process and the decimal places can be adjusted. The basic unit is displayed every time the device is started. -
Page 64: Running The "Statistics" Application
Operation 8.9.2 Running the “Statistics” Application The “Statistics” application saves up to 99 weight values and evaluates these statistically. The following values are saved and exported by the statistics application: — Number of components — Mean value — Standard deviation — Variation coefficient Sum of all values — Lowest value (minimum) —... -
Page 65: Cleaning And Maintenance
Cleaning and Maintenance Cleaning and Maintenance Preparing the Device for Cleaning Procedure If an accessory is connected to the device: Disconnect the accessory from the device (see instructions for the accessory). If the upper or lower cover for the rear wall of the weighing compartment is removed: Insert the cover for the weighing compartment into the rear wall of the weighing compartment (see Chapter 6.5, page 50). -
Page 66: Removing The Weighing Pan And Associated Components
— If there is a weighing pan with a shield plate: The shield plate (2) — Base plate of weighing compartment (3) Cleaning the Device Sartorius recommends cleaning the device at regular intervals, e.g. weekly. Do not allow deposits to form on the weighing pan. To clean the device, you can use the cleaning utensils supplied or a damp cloth. -
Page 67: Maintenance Schedule
Maintenance Schedule Interval Component Activity Chapter, Page 12 to 24 months, depending on Device Contact Sartorius Service. operating conditions Re-starting the System Procedure Reinstall the removed components back onto the device (see Chapter 5, page 44): — Draft shield — Weighing Pan and Associated Components —... -
Page 68: Performing A Software Update
— The device is connected to the power supply. — The USB mass storage device is formatted with file system “FAT32”. Procedure Download the software package from the Sartorius website onto the USB mass storage device. To do this, download the “Cubis ®... -
Page 69: Malfunctions
If the software update has conformity-assessed assessed devices. received corresponding device. approval: Sartorius Service can carry out the software update. Re-verification may then be necessary. INVALID If a USB mass storage No valid manufacturer... - Page 70 ERR 54 The modulation of An error exists in the Contact Sartorius Service. the weighing weighing system or in the converter inside the device electronics. weighing module is too low.
- Page 71 A memory error exists in the Switch the device off and on faulty. control unit. again. If the problem occurs again: Contact Sartorius Service. ERR 02 The device cannot be The device was not tared or Tare or zero the device. adjusted when zeroed before calibration.
-
Page 72: Malfunctions On The Operating Display Or During Weighing Processes
Malfunctions 10.3 Malfunctions on the Operating Display or During Weighing Processes Fault Cause Solution Chapter, Page The operating display The power supply unit is not connected to Connect the power supply 6.2, 49 is blank. the device. cable to the “Power Supply” connection. -
Page 73: Decommissioning
Decommissioning Decommissioning 11.1 Decommissioning the Device Procedure Disconnect the device from the power supply. Disconnect the device from all connections at the installation site. If an accessory is connected to the device: Disconnect the accessory from the device (see instructions for the accessory). If the upper or lower cover for the rear wall of the weighing compartment is removed: Insert the cover for the weighing compartment into the rear wall of the weighing compartment (see Chapter 6.5, page 50). -
Page 74: Transportation
Transportation 12 Transportation 12.1 Transporting the Device Requirements — The device has been decommissioned. — The operating display is secured to the device. Procedure CAUTION Risk of injury when lifting or transporting! Disconnect the device from all connections at the installation site. Use both hands when transporting the device and setting it down. -
Page 75: Storage And Shipping
Transport damage as well as measures for subsequent cleaning and disinfection of the device or parts by Sartorius are charged to the sender. Devices contaminated with hazardous materials, e.g., harmful biological or chemical substances, will not be accepted for repair or disposal. -
Page 76: Disposal
Disposal 14 Disposal 14.1 Disposing of the Device and Parts The device and the device accessories must be disposed of properly by disposal facilities. A lithium cell battery, type CR2032, is installed inside the device. Batteries must be disposed of properly by disposal facilities. Procedure Dispose of the device in accordance with local government regulations. -
Page 77: Technical Data
Technical Data 15 Technical Data 15.1 Dimensions and Weights 15.1.1 High-capacity Micro Balance Unit Value Dimensions Dimensions (L x W x H) 486 x 240 x 301 Dimensions (L x W x H), with operating display removed 376.5 x 240 x 301 Weighing pan size (diameter) With operating display removed: Max. -
Page 78: Ambient Conditions
Technical Data 15.3 Ambient Conditions Unit Value Installation site Standard laboratory rooms Installation site according to IEC 60259-1, maximum altitude above 3000 sea level For indoor use only Air pressure, maximum mbar 600 – 1200 Temperature In operation °C +5 – +40 In operation, with isoCAL function* °C +10 –... -
Page 79: Electrical Data
Technical Data 15.5 Electrical Data 15.5.1 Power Supply Unit Value Power supply only permitted using Sartorius power supply unit Sartorius network device, type 1000099844 Power supply at installation site (primary) AC voltage 100 – 240 ± 10% Frequency 50 – 60... -
Page 80: Interfaces
Technical Data 15.5.4 Interfaces USB-A connection Communication: USB host (master) USB-B connection Communication: USB device (slave) Type of interface: Virtual serial interface (virtual COM-port, VCP) and “PC direct” communication USB-C connection Communication: Downstream-facing port (DFP), USB host (Master) Communication: RS232 connection with accessory YCC-USB-C-D09M 15.6 Wait Times Unit Value... -
Page 81: Conditions For Isocal Function
Technical Data 15.9 Conditions for isoCAL Function Unit Value Possible Conditions for Triggering the isoCAL Function In the event of a temperature change After a time interval After successful leveling Only conformity-assessed devices: After interrupting the power supply Required Conditions for Executing the isoCAL Function Operating display is in weighing mode (not in menu) Alphanumeric inputs are not active. -
Page 82: Materials
Technical Data 15.13 Materials Housing Stainless steel 1.4401 | 1.4404, Aluminum Plastic PBT | PA Float glass Optiwhite Control unit: Plastic PBT | PP Float glass Stainless steel 1.4301 Weighing pan: Titanium Operating Instructions Cubis | MCE Models ®... -
Page 83: Cleaning Agents And Cleaning Procedures
Technical Data 15.14 Cleaning Agents and Cleaning Procedures 15.14.1 Approved Cleaning Agents Cleaning agents and concentration Device Components Ethanol, Isopropanol, Citric Diluted Sodium Ecolab™ acid, hydrogen hydroxide, Klercide peroxide, Sporicidal 3.5% Chlorine Draft shield Top door Left and right doors Front panel Components in the weighing compartment... -
Page 84: Metrological Data
Technical Data 15.15 Metrological Data 15.15.1 High-capacity Micro Balance MCE 36S-3 MCE 36P-3 MCE 66S-3 MCE 66P-3 Unit Value Value Value Value Scale interval (d) 0.001 0.001 | 0.01 0.001 0.001 | 0.01 Maximum capacity (Max) 10.1 | 32 12 | 61 Repeatability at 5% load Standard deviation of the load 0.001... -
Page 85: Accessories
YWP09-3 Under-pan hook for below-balance weighing On request Density determination set for solids and liquids YDK03MS Sartorius Wedge, software for data communication between the PC and device YSW02 Additional operating display (second display) YSD01 Operating Instructions Cubis | MCE Models... -
Page 86: Sartorius Service
Weighing scoop made from chrome-nickel steel, (90 mm x 32 mm x 8 mm) 641214 17 Sartorius Service Sartorius Service is at your disposal for queries regarding the device. Please visit the Sartorius website (www.sartorius.com) for information about the service addresses, services provided, or to contact a local representative. For inquiries about the system or when contacting Sartorius Service in the event of a malfunction, ensure that you have the device information, e.g.,... - Page 87 EN 61010-1:2010 +A1:2019 +AC2014-04 Die Person, die bevollmächtigt ist, die technischen Unterlagen zusammenzustellen: The person authorised to compile the technical file: Sartorius Lab Instruments GmbH & Co. KG Electronics & Product Compliance 37070 Goettingen, Germany Sartorius Lab Instruments GmbH & Co. KG...
