5. On the SIP Setup page, enter values for the parameters indicated in
Web Page Item
SIP Settings
SIP Server
Remote SIP Port
Local SIP Port
Outbound Proxy
Outbound Proxy Port
SIP User ID
Authenticate ID
Authenticate Password
Register with a SIP Server
Re-registration Interval (in seconds)
Unregister on Reboot
Buffer SIP Calls
1. Enter the IP address of the SIP Server.
2. Enter the port numbers used for SIP signaling:
3. Enter the SIP registration parameters:
CyberData Corporation
Table 2-8. SIP Configuration Parameters
a. Remote SIP Port
b. Local SIP Port
a. SIP User ID
Description
Type the SIP server represented as either a numeric IP address
in dotted decimal notation or the fully qualified host name (255
character limit [FQDN]).
Type the Remote SIP Port number (default 5060)
(8 character limit).
Type the Local SIP Port number (default 5060)
(8 character limit).
Type the Outbound Proxy as either a numeric IP address in
dotted decimal notation or the fully qualified host name
(255 character limit [FQDN]).
Type the Outbound Proxy Port number (8 character limit).
Type the SIP User ID (up to 64 alphanumeric characters).
Type the Authenticate ID
(up to 64 alphanumeric characters).
Type the Authenticate Password (up to 64 alphanumeric
characters).
Enable or disable SIP Registration.
For information about Point-to-Point Configuration, see
"Point-to-Point Configuration".
Type the SIP Registration lease time in seconds (default is 60
minutes) (8 character limit). Re-registration Interval (in seconds)
When selected, on boot, the device will first register with a SIP
server with a expiration delay of 0 seconds. This has the effect
of unregistering any current devices on this extension.
When this is enabled, SIP calls to the device will be stored in
memory and will play when either the call is terminated or the
buffer is full. The receive buffer is 2MB in size and this is equal
to about four minutes of ulaw encoded audio.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
930367H
Setting Up the V2 Paging Server
Configuring the V2 Paging Server
Table 2-8.
2.4.6.1,
