CyberData VoIP V2 Operation Manual page 24

2. On the Device Configuration page, you may enter values for the parameters indicated in
Table
Web Page Item
Miscellaneous Settings
Beep on Initialization
Enable Line In to Line Out
Loopback
Enable Line-In to Multicast
3. After changing the parameters, click the Save button.
CyberData Corporation
2-6.
Table 2-6. Device Configuration Parameters
Description
When selected, you will hear a beep when the speaker initializes.
When selected, audio is sent from the line -in to the line-out output.
When selected, the line-in audio will be multicast to the address and
port specified on the web page.
Note: Ideally, the specified address and port will match that of a low
priority MGROUP (such as background music) on the speakers or
paging amplifiers.
Note: When line-in to multicast is selected, do not set that multicast
address and port to the same multicast address and port that is used
by one of your PGROUPS. Otherwise, when you call the PGROUP,
the Paging Server will be unable to send the new audio stream
because the port will already be in use by the line-in to multicast
stream.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Test Audio button to do an audio test. When the Test
Audio button is pressed, you will hear a voice message for testing the
device audio quality and volume.
Click on the Reboot button to reboot the system.
930367H
Setting Up the V2 Paging Server
Configuring the V2 Paging Server
Operations Guide
16
