R
HARDWIRE
CONTROL PANEL/COMMUNICATOR
"Classic" GEM-RP2ASe2, GEM-RP3DGTL, and GEM-RP4RFC/GEM-RP4C Keypads and
the "K Series" GEM-K2AS, GEM-K3DGTL, and GEM-K4RF/GEM-K4 Keypads
GEMINI
SYSTEM ARMED
01/01/97 12:00AM
A
1 2
R
B
4
5 6
C
7 8 9 0
COMPUTERIZED SECURITY SYSTEM
"K Series" GEM-K2AS
Quick Start (for GEM-K2ASe2):
1.
Refer to the wiring diagram, connect Siren, Aux. Power,
PGM Output, Remote Bus, Earth Ground, Zone and Tele-
phone Wiring. NOTE: See Installation Instructions (WI742).
2.
Connect AC power first and then the battery.
3.
Configure the keypad (see page 64).
4.
Access the Easy Menu Driven (Dealer Program) Mode:
Press:
EEEEEE
Master Security Code
(on microshield)
Press NO until "TURNON PROG Y/N" appears on the keypad display.
Press NEXT/YES to enter Dealer Program Mode. See p. 5
© Napco 2003
G E M - P 9 6 0 0
Programming the GEM-P9600 Control Panel with the
"K Series" GEM-K4RF/GEM-K4
READY
READY
AC ON
AC ON
NEXT/YES
3
E
D
PRIOR/NO
F
AREA
G
R
R
PROGRAMMING
INSTRUCTIONS
WIRELESS
GEMINI
SYSTEM ARMED
32
01/01/97 12:00AM
INTERIOR
A
1 2
R
B
4
5 6
C
7 8 9 0
COMPUTERIZED SECURITY SYSTEM
"K Series" GEM-K3DGTL
Quick Start (for GEM-K3DGTL):
1.
Refer to the wiring diagram, connect Siren, Aux. Power,
PGM Output, Remote Bus, Earth Ground, Zone and Tele-
phone Wiring. NOTE: See Installation Instructions (WI742).
2.
Connect AC power first and then the battery.
3.
Configure the keypad (see page 64).
4.
Access the Easy Menu Driven (Dealer Program) Mode:
Press:
EEEEEE
Master Security Code
(on microshield)
Press NO until "17" appears on the keypad display.
Press NEXT/YES to enter Dealer Program Mode. See p. 5.
ENT A1
BYPASS
FIRE/TBL
SYS TBL
CHIME
NEXT/YES
3
E
D
PRIOR/NO
F
AREA
G
R
R
WI 1185 6/03
