Split Screen With Route Guidance - Becker Map Pilot Operating Manual

>>> NAVIGATION MODE
Current road
7
or
> EN
Traffic lane recommendation (only
appears on some multi-lane roads;
green arrows = recommended lanes)
Note:
Following the traffic lane recommenda-
tions allows you to perform the next driv-
ing manoeuvre without changing lanes.
Distance to next driving manoeuvre
8
Next driving manoeuvre
9
Estimated time of arrival, remaining
10
journey time and remaining distance
to destination
Your current position is displayed on the
map via the position icon.
Information is also displayed on the left in
the preview area.
35
The next manoeuvre is displayed as an ar-
row, with the distance to the next ma-
noeuvre point indicated underneath it. If
two driving manoeuvres are to be per-
formed in succession within a short time,
another smaller arrow indicating the sec-
ond driving manoeuvre is displayed above
the first arrow.
Information on the TMC status is dis-
played in the bottom line. There are three
possible TMC statuses:
If the first icon is displayed, TMC is oper-
ating correctly.
If the second icon is displayed, there is a
hold-up on the route.
If the third icon is displayed, TMC recep-
tion is disrupted and no TMC messages
can be received.

Split screen with route guidance

11
10
9
6
8 8
7 5
Road signs, which you should follow
1
Speed limit on the road currently be-
2
ing driven on (display not available
for all roads)
Driver alerts
3
Number of satellites currently being
4
received
Display of TMC status
5
Vehicle position
6
Current road
7
or
Traffic lane recommendation (only
appears on some multi-lane roads;
green arrows = recommended lanes)
1
2
3
4
