AD9883A
OUTLINE DIMENSIONS
Dimensions shown in inches and (mm).
80-Lead LQFP
(ST-80)
0.063 (1.60)
0.630 (16.00) BSC SQ
MAX
0.551 (14.00) BSC SQ
0.030 (0.75)
0.024 (0.60)
80
0.018 (0.45)
1
SEATING
PIN 1
PLANE
COPLANARITY
0.004 (0.10)
20
MAX
21
0.006 (0.15)
0.002 (0.05)
0.008 (0.20)
0.0256 (0.65)
BSC
0.004 (0.09)
CONTROLLING DIMENSIONS IN MILLIMETERS.
CENTER FIGURES ARE NOMINAL UNLESS OTHERWISE NOTED.
61
60
TOP VIEW
(PINS DOWN)
41
40
0.057 (1.45)
0.055 (1.40)
0.053 (1.35)
0.015 (0.38)
7
3.5
0.013 (0.32)
0
0.009 (0.22)
