lI . . . .
vat.ncI ...
pllle .......
' ....... 1-18. C .......... acrew R ....
ov.1
3.
Use needlenose pliers to remove the rectangular dip holding the printhead flex cable in the bot-
tom of the mechanism.
4.
Remove the
two
E-rings from the ends of the carriage shaft. Remove the shaft and carriage as-
sembly. Feed the flex cable through the slot in the bottom of the mechanism as you do so.
Plnch·Roll_ R.plac .... nt. To replace the pinch roller, follow these steps:
'I.
Remove the screw on the left end of the bail shaft.
2.
Remove the left E-ring and slide the left pinch roller off the shaft. If the right pinch roller requires
replacement, remove the next
two
E-rings and slide the right pinch roller off the left end of the
shaft.
Not.: After you replace the pinch rollers, E-rings, and the screw, ensure that the rollers spin
freely on the shaft. Adjust the pinch rollers for equal presure on the paper (refer to • Adjusting
the Bail Arm)_
.
. . II-A ... mb., Repl.e.en" To remove the bail assembly, follow these steps:
'I.
lift the right-hand bail spring to the outward position, pinch the legs together, and lift
it
out.
o
Repeat with the left-hand bail spring. See figure 6-19.
