52 en | Operation
2.8.8

Change/View Output State

From the Service menu (Figure 2.64, Page 39), select Change/View Output State. The
Change/View Output State screen (Figure 2.93, Page 52) opens showing a list of all outputs.
–
–
Figure 2.93 Change/View Output State screen
Pressing the output buttons changes the state of the outputs. To search the list for a specific
output, press the Search button. The Search Change/View Output State screen (Figure 2.94,
Page 52) opens. Use the numeric, alphabetic, and command keys to enter the name of an
output. The name appears in the field at the top of the screen. Press the Enter button to start
the search.
Figure 2.94 Search Change/View Output State screen
To sort or filter the list of outputs, press the Sort/Filter button on the Change/View Output
State screen. The Sort/Filter Change/View Output State screen (Figure 2.95, Page 53) opens.
Press a button to select one of the following lists:
–
–
–
F.01U.168.328 | 03 | 2011.05
Output is Off ( ), or
Output is On ( ).
List All Outputs
List "Off" Outputs
List "On" Outputs
