MAP Control Center
Figure 2.8 Arm Selected Areas screen
To sort the list of areas before selecting some to arm, press the Sort/Filter button. Refer to
Table 2.3, Page 15 for the possible arming indicators.
Indicator
Disarmed
Ready to Arm
Not Ready to Arm
Armed
Table 2.3 Arming indicators
2.3.3

Arm Control Panel (Local) Area

From the Arm menu (Figure 2.5, Page 13), press the Arm Control Panel Area button.
NOTICE!
Depending on how your system is configured, the displayed button name on each control
center is unique for each installation.
The Arm menu opens with the lock button in the locked position and the area's armed status
showing on the Arm Control Panel Area button.
2.4 Disarm – Using the Control Center
The Disarm menu allows the user to disarm all areas, disarm selected areas, or disarm the
entire control panel (or installation-specific local) area. On the Main Menu (Figure 1.5,
Page 8), press Disarm, then select a disarming option from the on-screen buttons on the
Disarm menu (Figure 2.9, Page 16).
Bosch Security Systems, Inc.
Description
Area currently disarmed
All points in the area are ready
to arm
Some points in the area are
faulted and not ready to arm; all
points must either be returned
to normal or bypassed.
Area currently armed
