1.2 Names of Parts

1.2.1 External View

[1]
[1]
[2]
[3]
[4]
[5]
[6]
[12]
[13]
[14]
[2] [3]
Operation panel
ADF (Auto Document Feeder)
Document feeder tray
Document guides
Output tray
Cartridge cover
[12]
[13]
[14]
USB port
Power socket
Face up cover
[4]
[5]
[6]
[7]
[8]
F-1-1
[7] Front cover
[8] Cassette
[9] Platen glass cover
[10] Platen glass
[11] Multi-purpose tray
[17]
LINE
[15][16]
F-1-2
[15] Telephone line jack
[16] External device jack
[17] Ethernet port
