5.4.3 Dump HEX

[Dump HEX] uploads the user program stored on the PG-FP3 to FLASHPRO3 (host side). The uploaded data can
be checked by using the [Edit] command.
Execute this command by selecting [Dump HEX] from the [Other] pull-down menu or by clicking the
button on the operation screen. When this command is executed, the following dialog box opens, and the addresses
to which the program is to be uploaded can be specified.
About [Edit]
[Edit] is used to check the data loaded into or uploaded to FLASHPRO3. The displayed data can be also
edited.
Execute this command by clicking the
When the command is executed, the following window opens and data can be listed or edited.
CHAPTER 5 COMMAND REFERENCE
button on the operation screen.
Figure 5-3. Editor Screen
User's Manual U13502EJ2V0UM00
65
