CHAPTER 4 BASIC OPERATING PROCEDURE
Turn on power to the PG-FP3.
Confirm that the LED on the PG-FP3 is blinking.
Start FLASHPRO3.
If the communication error dialog box opens at this time, check the [Connection Port] setting and
change if necessary.
The example below assumes that the PG-FP3 is connected to LPT1.
Figure 4-1. Communication Error Dialog Box
Open the setting dialog box by clicking [Connection Port].
Change the setting for Connection Port from COM1 to LPT1.
After changing the setting, click the [OK] button.
The error dialog box will be displayed again. Execute [Retry] for reconnection.
