Zaxcom Nomad User's Manual_____________________________________________________Chapter 2

Analog Input Channel Setup page

Page purpose:
How to get here:
(SETUP key once)
While in this page, pressing any of the multi-function keys will select the input channels one through ten. An input
meter is provided to help adjust the trim.
Press and rotate the MENU knob to select and change each channel input function. Channel input functions
include: input trim, input type, channel delay, highpass filter, phase, compressor limiter, phantom power enable
and two notch filters. Use the HEADPHONE knob to return to the
separate On/Off and frequency adjustments. The notch frequency can be entered by using the number keys, as
well as the MENU knob.
NOTE: The HPF button does double duty. Turning it ON turns on an analog filter with a fixed cutoff frequency
of 100 Hz and a digital filter with the cutoff frequency controlled by the HPF FREQ button.
Headphone-1 page
Page purpose:
How to get here:
(simultaneously press MENU knob and HEADPHONE knob)
Nomad's main monitor connection can retain up to 12 Monitor Presets, each consisting of any combination of card
tracks, output busses or returns. If selected, wireless microphone receivers can be monitored directly through the
ZaxNet System on Nomad 6, 8 and 12.
NOTE: The ZaxNet monitor points feed the headphones as split mono. Only one can be enabled at a time.
To create those User Presets, see
From the
press it to move to the NEXT preset
press and hold it to move to the PREVIOUS preset
This page controls the operating parameters for each of the analog inputs.
This page controls which audio busses are routed to the Headphone-1 connector.
Retaining Your Headphone Mix with a Monitor Preset
Home page
{p.23}, you can cycle through the Monitor Presets using the HEADPHONE knob:

Figure 2-20 Analog Input Channel Setup page

Figure 2-21 Headphone-1 Monitor Sources page

35
Home page
{p.23}. Each notch filter has
{p.63}.
