Chapter 2 - Software Guide; Boot-Up Sequence Page; Figure 2-1 Boot-Up Sequence Page - Zaxcom Nomad User Manual

Chapter 2_____________________________________________________Zaxcom Nomad User's Manual
The Nomad is a very sophisticated recording device. The heart of the system is the software used to operate the
device. This chapter describes every Nomad page and the functions within each.

Boot-up Sequence page

Page purpose:
How to get here:
IMPORTANT: If you ever see
How bad is it to see RED text during boot-up? It depends. It may mean there are errors on the card or
something is corrupted in non-volatile memory.
NOTE: Powering on the unit and holding the MENU knob (just after the unit has started printing text) will
freeze the display and allow the Operator to see any warning(s).
Chapter 2 – Software Guide
This page shows the processing necessary to initialize the Nomad.
Turn 'ON' the Nomad.
Dec 28 2011 14:41:41
Init RTC: Temperature=79F:78F
HD-CF reset(2)
INT=0.0 EXT=0.0V
Aud=13 Main=55 DSP=0B
Flash system init:
Loading saved settings...
==== DSP SPEED = 294.912 ====
Initializing battery backed clock
RTC INIT PASSED Minutes ON = 26106
Synchronizing clocks...
Initializing audio...
INT DISK: SN=20081114
TRANSCEND (16.0GB)
-- Checking folder[1] (13 segs) --
InitModules...

Figure 2-1 Boot-up Sequence page

RED text during boot-up, make note of it.
gM:V3
48V=8.1V C=0.0V
CF1332C0
22
done
