Chapter 1_____________________________________________________Zaxcom Nomad User's Manual

Left Side Description

1.
7.
10.
Battery Compartment Area (behind the door)
1. External Power connector (Hirose-4F)
(8 to 18 VDC {1/2 A @ 12 VDC}) (See
WARNING: Do NOT connect the external power connector to a source higher than 18.0 VDC.
This is the ABSOLUTE upper limit. If you exceed it by even 0.1 VDC, you will BLOW the unit's power
supply and require it to be sent in for maintenance. The warranty will be VOID if it is determined that the
power supply was blown by violating this warning.
2. AES Input/Output connector (DE-15F)
(See
3. TC Output connector (BNC)
4. TC Input connector (BNC)
2.
8.
11. 12.
AES Digital Input / Output Connectors (DB-15)
3. 4. 5.
9.
Unit Left Side View
Battery Carrier (w/ 6 batteries installed)

Figure 1-2 Nomad Left Side Images

Power Connector (Hirose-4 Connector)
{p.70}.)
16
6.
Battery Connector (far end)
{p.69}.)
