Zaxcom Nomad User's Manual_____________________________________________________Chapter 2

Home page

Page purpose:
How to get here:
Turn the power on and let the system initialize.

Page Notes

Once the boot process has completed, one of the configurations shown in

Transport Status field

(Figure 2-2
Located at the top of the page, it displays the current operating mode (RECORD,

Timecode field

(Figure 2-2
Located at the top of the page, it displays the current timecode based on the source selected in the
Setup page

Headphone Monitor field

(Figure 2-2

Prefader Listen field

Once the PFL key is pressed, the name in the Headphone Monitor field is replaced with PFL alternating with the
selected channel number(s) as follows:
Pressing the corresponding multi-function key will select the channel you are listening to. If you want to listen to
multiple channels at the same time just hold an additional multi-function key for approximately 1 second to add
that channel to the PFL circuit.
Press the HEADPHONE knob to restore normal headphone monitoring.

Mirror Status

(Figure 2-2

Battery icon

(Figure 2-2
It indicates the power source (I / E), a numeric display of the current voltage and a color bar, indicating the state
of charge. Once the voltage reaches the level specified in the
background changes to Red and optional beeps to the primary headphones are triggered.

Time Left (TL) display

(Figure 2-2
This field indicates the recording time remaining on the Primary card, at the current track count and sampling-rate.
This page displays the current status for the recorder and its major components.
Figure 2-2 Home page (ENG Home page selected)
{p.23} displays STOP)
{p.23} displays 00:08:39:15)
{p.28}.
{p.23} displays HP 1)
{p.23} displays MIR 1 OF 20)
{p.23} displays E inside of the Battery icon)
{p.23} displays TL 01:02:03)
Warnings Setup page
23
Figure 2-3 {p.25} is displayed.
PLAY or STOP).
Timecode
{p.51}, the color of the
