Zaxcom Nomad User's Manual_____________________________________________________Chapter 1
System
Features

Nomad-4

4 recording tracks on dual CompactFlash cards

Nomad-6

6 recording tracks
6-channel AES input with sample-rate conversion
6-channel AES output
2-channel AES-42 input with sample-rate conversion
6-channel auto-mixer
ZaxNet IFB, timecode and wireless microphone remote control system

Nomad-8

(INCLUDES NOMAD-6 FEATURES and ...)
8 recording tracks
High-speed USB storage interface
Wi-Fi USB modem file transfer
3 media recording capability with MP3 transcription

Nomad-12

(INCLUDES NOMAD-8 FEATURES and ...)
12 recording tracks
10-channel auto-mixer

Common Features

Input

6 – XLR-3F mic/line level, balanced
4 – balanced line-level, camera return or mix
115dB dynamic range
External slate mic input
Zaxcom ultra low noise, ultra low distortion transformerless preamps

Output

4 – XLR-3M, balanced
3 – TA-5M, balanced (6 busses)
Selectable output levels: 0dB, -10dB & -30dB
2 – mono and tape outputs: 1/8"
2 stereo headphone connectors: 1/4", 1/8"

Mixer

6-fader integrated mixing surface
32-bit floating point DSP
16 input x 16 output (pre-fader / post-fader / phase inversion)
All effects and mixing in digital realm

Effects

Analog Highpass filter
Channel Dynamics: High-pass filter, 2 notch filters, delay, limiter, soft knee compressor
Bus Dynamics: Soft knee compressor

Recording

Record on dual CompactFlash cards
Media instantly removeable
Pre-record buffer: 0 - 10 seconds
Files systems: MARF & FAT32
Metadata: Standard iXML
Sample-rates (kHz): 44.1, 47.952, 48, 48.048, 88.2, 96
11
