Zaxcom Nomad User's Manual_____________________________________________________Chapter 1
This is a multi-function control. Press it to backout of a menu to the previous menu. Turn it to adjust the
headphone #1 volume.
13. Star (*) key
Pressing it:
A) In the
B) In the
C) While powering-up, starts the software update process (see
14. Fader 1 (of 6 total)
Each of these can be assigned to any channel or combination of channels, or act as a hardware trim knob.
15. Fader 1 SOLO LED (of 6 total)
It indicates which fader is active for Auto-trim.
16. SLT / 8 / 0 key
(Slate Mic key)
A) Press and hold it to open the current Slate source (int/ext) and the audio is routed according to the Slate
B) When a number is needed in a data entry field or need to select a channel #:
17. MENU knob / SHIFT key
This is a multi-function control. Turn it to select one of the menu items. Press it to select the currently
highlighted menu item. In a few situations, pressing it while pressing another key changes what happens while
pressing that second key.
NOTE: while scrolling through a parameter with a long list, pressing the MENU knob while turning it will often
speed up the scroll speed by 10 times.
Home page {p.23}, it advances to the next configuration (see
Bus Routing page {p.29}, it inverts the input phase in the matrices of several pages.
{p.71})
(S) column in the busses. The source (INTERNAL/EXTERNAL) is selected with the SLATE SOURCE
button on the Mode page
press it for the number/channel 8
double click it for the number/channel 0
{p.46} and the level is managed by the
15
Figure 2-3 {p.25}).
Upgrading the Firmware in Each Unit
Input Levels page {p.51}.
